▶ EngineEngine Manufacturer Iseki TYM Engine Model Not Published A1100N2 Engine Type 3-cylinder, liquid-cooled diesel 3 cylinder, water-cooled diesel, swirl chamber, natural aspiration No. of Cylinders 3 3 Displacement 91.4 in³ 70.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 24 hp 24 hp PTO Power Mech: 20.4 hp; HST: 19.2 hp 18 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Dry element Fuel System Not Published Indirect injection (swirl chamber) Alternator Not Published 50 A, 12 V ▶ HydraulicsPump Type Two gear-type pumps Gear type pump with primary and secondary pumps Implement Flow 7.3 gpm 4.3 gpm Steering Flow 3.6 gpm 3.1 gpm Total Hydraulic Flow 10.9 gpm (7.3 + 3.6, computed) 7.4 gpm Overall Hydraulic Pump Flow 10.9 gpm (7.3 + 3.6, computed) 7.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 10 gal 6.08 gal Coolant Capacity Not Published 1.21 gal Crankcase Capacity Not Published 0.79 gal Transmission / Hydraulic System Capacity Not Published 2.90 gal Front Axle Fluid Capacity Not Published 0.79 gal ▶ PTO & HitchPTO Type Mech: Independent; HST: Transmission Live PTO (6 spline shaft) PTO Rear 540 rpm, 1.375 in 540 / 960 rpm Mid-PTO Availability Not Published Optional, 2,500 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity 2,205 lb 1,433 lb Hitch Lift Capacity (at 24”) 1,598 lb 974 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Mech: 8x8 synchro shuttle; HST: 3-range hydrostatic Hydrostatic (HST) No. of Speeds Mech: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 3 range (L/M/H) Max Travel Speed (Forward) Not Published 14.8 mph Max Travel Speed (Reverse) Not Published 14.8 mph Clutch Not Published Dry, single plate Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Steel frame with cast iron axles Steering Power steering Hydrostatic power steering Brakes Not Published Wet disc Seat Suspension & Adjustability Not Published Adjustable seat, flips up and back for rear backhoe operation Front Axle Type Not Published Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.5 in 110 in Overall Width 52.4 in 53.9 in Wheelbase Not Published 65.7 in Ground Clearance 11 in 16.4 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 97.6 in 91.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2,668 lb 2,107 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural (11.2-20 rear standard), R4 Industrial (25x8.50-14 / 14-17.5) R1 Agricultural - Front Not Published 7-16 6PR R1 Agricultural - Rear Not Published 11.2-20 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 25x8.50-14 R4 Industrial - Rear Not Published 14-17.5 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer quick attach Quick attach front loader Loader Model FL2407X BBL300 Loader Lift Height FL2407X: 94.3 in 87.5 in Loader Lift Capacity (Full Height) FL2407X: 1,450 lb 1,314 lb Loader Breakout Force FL2407X: 2,288 lb 1,960 lbf ▶ WarrantyWarranty Length & Coverage Not Published Engine and powertrain: 72 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
