▶ EngineEngine Manufacturer Iseki Shibaura Engine Model Not Published Shibaura N3LDI-T Engine Type 3-cylinder turbocharged diesel, liquid-cooled 3-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 3 3 Displacement 111.4 in³ 101.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 39.4 hp 40 hp PTO Power 33.5 hp 31.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Not Published Common rail direct injection Alternator Not Published Not Published ▶ HydraulicsPump Type Two gear-type pumps, one for steering and one for 3-point and remotes Engine-driven gear-type pump Implement Flow 7.6 gpm 11.0 gpm Steering Flow 3.8 gpm Not Published Total Hydraulic Flow 11.4 gpm Not Published Overall Hydraulic Pump Flow Not Published 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 10.56 gal Coolant Capacity Not Published 6.34 qt Crankcase Capacity Not Published 4.86 qt Transmission / Hydraulic System Capacity Not Published 12x12 Power Shuttle: 8.18 gal; HST: 7.4 gal Front Axle Fluid Capacity Not Published 7.9 qt ▶ PTO & HitchPTO Type 8x8 Synchro Shuttle: independent; HST: transmission driven Independent, with soft-start feature PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I with extendable ball ends Hitch Lift Capacity 2,205 lb 2,646 lb Hitch Lift Capacity (at 24”) 1,598 lb 2,535 lb Lift Control Type Not Published Position and draft control ▶ Transmission & DrivetrainTransmission Type 8 x 8 synchro shuttle or 3-range hydrostatic 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds 8x8 Synchro Shuttle: 8F / 8R; HST: 3-range infinite 12x12 Power Shuttle: 12F / 12R; HST: 3-range infinite Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Single stage dry type Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Internal wet disc brakes, individual control via independent foot pedals Seat Suspension & Adjustability Not Published Deluxe suspended seat with armrests and seatbelts (vinyl seat on ROPS, cloth seat on cab), tilt steering Front Axle Type Not Published Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.5 in 122.0 in Overall Width 52.4 in 64.2 in Wheelbase Not Published 69.7 in Ground Clearance 11.0 in 15.4 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 97.6 in 99.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 91.3 in ▶ WeightTractor Weight (Base) 2,877 lb 12x12 Power Shuttle: 3,373 lb; HST: 3,406 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 8-16 R1 Agricultural - Rear Not Published 12.4x24 R3 Turf - Front Not Published 27x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System FLx2407: skid steer quick attach DL125: Pin-on (skid steer quick attach optional) Loader Model FLx2407 DL125 Loader Lift Height FLx2407: 94.3 in DL125: 106 in Loader Lift Capacity (Full Height) FLx2407: 1,450 lb DL125: 1,660 lb Loader Breakout Force FLx2407: 2,288 lb DL125: 3,000 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
