▶ EngineEngine Manufacturer Simpson LS Mtron Engine Model SJV326 L3C19-T Engine Type 3-cylinder, turbocharged, intercooled, liquid-cooled diesel Diesel, 3-cylinder, turbocharged No. of Cylinders 3 3 Displacement 157.9 in³ 116 in³ Rated Engine Speed 2000 rpm 2600 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 38 hp 36 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Replaceable dry element Fuel System Electronically controlled high-pressure common rail Common rail direct injection Alternator Not Published 70 A ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Not Published Implement Flow Not Published 8.2 gpm Steering Flow Not Published 5.3 gpm Total Hydraulic Flow 15.7 gpm Not Published Overall Hydraulic Pump Flow 15.7 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 10.5 gal Coolant Capacity 4 gal Not Published Crankcase Capacity 2.5 gal Not Published Transmission / Hydraulic System Capacity 10.5 gal Not Published Front Axle Fluid Capacity 4WD: 1.5 gal differential, plus 0.23 gal per wheel end Not Published ▶ PTO & HitchPTO Type Live Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm, 6-spline 540 rpm Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I and II Category 1 Hitch Lift Capacity 3,747 lb 2,756 lb Hitch Lift Capacity (at 24”) 2,204 lb 2,469 lb Lift Control Type Draft, position and response control Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type 8F x 2R SideShift sliding gear 3-range hydrostatic (HST) No. of Speeds 8 forward and 2 reverse infinitely variable, 3 ranges Max Travel Speed (Forward) Not Published 17.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dual dry Not Applicable Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering with separate reservoir Power steering Brakes Drum brakes Wet multi-disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Adjustable suspension seat Front Axle Type 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 138 in; 4WD: 139 in 128.1 in Overall Width 64.6 in 69.1 in Wheelbase 2WD: 80.7 in; 4WD: 81.5 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 90.6 in 97.1 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model Not Published 93.3 in ▶ WeightTractor Weight (Base) 2WD: 4,597 lb; 4WD: 4,927 lb 3,770 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD standard (ag): 6x16 front, 12.4x28 rear; 2WD optional (ag): 7.5x16 front, 13.6x28 rear; 4WD standard (ag): 10.5/80-18 front, 12.4x28 rear R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 2WD: 6x16 (7.5x16 optional); 4WD: 10.5/80-18 9.5-16 R1 Agricultural - Rear 2WD: 12.4x28 (13.6x28 optional); 4WD: 12.4x28 13.6-24 R3 Turf - Front Not Published 28x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 12-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling Quick-Attach faceplate; quick-connect loader mounting (L360A) Loader Model FLx2815 (2WD); 911X (4WD) L360A Loader Lift Height FLx2815: 111 in; 911X: 114 in 112 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb; 911X: 2,470 lb 2,500 lb Loader Breakout Force FLx2815: 4,240 lb; 911X: 2,755 lb 3,114 lbf ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 6-year (72-month) extended warranty: 2-year bumper-to-bumper plus 4 additional years powertrain
