▶ EngineEngine Manufacturer Simpson KIOTI (Daedong) Engine Model SJV326 3F183T Engine Type 3-cylinder, turbocharged, intercooled, liquid-cooled diesel KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 3 3 Displacement 157.9 in³ 111.4 in³ Rated Engine Speed 2000 rpm 2600 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 38 hp 33.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Dry type element Fuel System Electronically controlled high-pressure common rail Common Rail Direct Injection (CRDI) Alternator Not Published Not Published ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Gear Implement Flow Not Published 9.6 gpm Steering Flow Not Published 8.2 gpm Total Hydraulic Flow 15.7 gpm 17.9 gpm Overall Hydraulic Pump Flow 15.7 gpm 17.9 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 14.8 gal Coolant Capacity 4 gal 2.0 gal Crankcase Capacity 2.5 gal 1.58 gal Transmission / Hydraulic System Capacity 10.5 gal 11.89 gal Front Axle Fluid Capacity 4WD: 1.5 gal differential, plus 0.23 gal per wheel end 1.8 gal ▶ PTO & HitchPTO Type Live Independent PTO Rear 540 rpm, 6-spline 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I and II Category I Hitch Lift Capacity 3,747 lb 3,538 lb Hitch Lift Capacity (at 24”) 2,204 lb 3,177 lb Lift Control Type Draft, position and response control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type 8F x 2R SideShift sliding gear Hydrostatic No. of Speeds 8 forward and 2 reverse 3 Range Max Travel Speed (Forward) Not Published 16.52 mph Max Travel Speed (Reverse) Not Published 16.52 mph Clutch Dual dry Not Published Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering with separate reservoir Hydrostatic Power Steering Brakes Drum brakes Wet Multi Disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Adjustable Seat Front Axle Type 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 138 in; 4WD: 139 in 139.6 in Overall Width 64.6 in 65.6 in Wheelbase 2WD: 80.7 in; 4WD: 81.5 in 75.6 in Ground Clearance Not Published 13.8 in Min. Turn Radius without Brakes Not Published 9.8 ft Height to Top of ROPS 90.6 in 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2WD: 4,597 lb; 4WD: 4,927 lb 4,000 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD standard (ag): 6x16 front, 12.4x28 rear; 2WD optional (ag): 7.5x16 front, 13.6x28 rear; 4WD standard (ag): 10.5/80-18 front, 12.4x28 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 2WD: 6x16 (7.5x16 optional); 4WD: 10.5/80-18 8-16 R1 Agricultural - Rear 2WD: 12.4x28 (13.6x28 optional); 4WD: 12.4x28 13.6-24 R3 Turf - Front Not Published 29-12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 14.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model FLx2815 (2WD); 911X (4WD) KL6010 Loader Lift Height FLx2815: 111 in; 911X: 114 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) FLx2815: 2,810 lb; 911X: 2,470 lb KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force FLx2815: 4,240 lb; 911X: 2,755 lb KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
