▶ EngineEngine Manufacturer Simpson Mahindra Engine Model SJV326 Not Published Engine Type 3-cylinder, turbocharged, intercooled, liquid-cooled diesel Four-stroke, naturally aspirated, direct injection, water cooled diesel No. of Cylinders 3 4 Displacement 157.9 in³ 166.2 in³ Rated Engine Speed 2000 rpm 2300 rpm Engine Power (Gross) 45 hp 45 hp PTO Power 38 hp 38 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Not Published Fuel System Electronically controlled high-pressure common rail Direct injection Alternator Not Published 55 A ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Not Published Implement Flow Not Published 8.71 gpm Steering Flow Not Published 4.62 gpm Total Hydraulic Flow 15.7 gpm 13.3 gpm Overall Hydraulic Pump Flow 15.7 gpm 13.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 17.1 gal Coolant Capacity 4 gal Not Published Crankcase Capacity 2.5 gal Not Published Transmission / Hydraulic System Capacity 10.5 gal Not Published Front Axle Fluid Capacity 4WD: 1.5 gal differential, plus 0.23 gal per wheel end Not Published ▶ PTO & HitchPTO Type Live Independent PTO Rear 540 rpm, 6-spline 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II CAT I & II with telescopic stabilizers & flex links Hitch Lift Capacity 3,747 lb Not Published Hitch Lift Capacity (at 24”) 2,204 lb 3748 lb Lift Control Type Draft, position and response control Position control ▶ Transmission & DrivetrainTransmission Type 8F x 2R SideShift sliding gear Full synchromesh with forward/reverse synchro shuttle & constant mesh range No. of Speeds 8 forward and 2 reverse 12F / 12R Max Travel Speed (Forward) Not Published 17.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dual dry Dual dry with cerametallic lining Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering with separate reservoir Hydrostatic power steering with tilt steering wheel Brakes Drum brakes Fully-enclosed, 7-in diameter, dry disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Adjustable seat with contoured cushions, armrests and a soft-coil suspension Front Axle Type 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 138 in; 4WD: 139 in 136.6 in Overall Width 64.6 in 74.8 in Wheelbase 2WD: 80.7 in; 4WD: 81.5 in 77.9 in Ground Clearance Not Published 15.2 in Min. Turn Radius without Brakes Not Published 10.8 ft Height to Top of ROPS 90.6 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2WD: 4,597 lb; 4WD: 4,927 lb 5390 lb Weight with ROPS and Loader Not Published 6,690 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD standard (ag): 6x16 front, 12.4x28 rear; 2WD optional (ag): 7.5x16 front, 13.6x28 rear; 4WD standard (ag): 10.5/80-18 front, 12.4x28 rear R1 Agricultural or R4 Industrial R1 Agricultural - Front 2WD: 6x16 (7.5x16 optional); 4WD: 10.5/80-18 9.5 x 20 R1 Agricultural - Rear 2WD: 12.4x28 (13.6x28 optional); 4WD: 12.4x28 14.9 x 28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 10.5/80 x 18 R4 Industrial - Rear Not Published 16.9 x 24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling Skid-steer style quick-attach coupler Loader Model FLx2815 (2WD); 911X (4WD) 5155-4L (front loader); 65B (rear backhoe) Loader Lift Height FLx2815: 111 in; 911X: 114 in 5155-4L: 122 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb; 911X: 2,470 lb 5155-4L: 3,100 lb Loader Breakout Force FLx2815: 4,240 lb; 911X: 2,755 lb 5155-4L: 5,200 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year limited powertrain warranty
