▶ EngineEngine Manufacturer Simpson Iseki Engine Model SJV326 Not Published Engine Type 3-cylinder, turbocharged, intercooled, liquid-cooled diesel 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 4 Displacement 157.9 in³ 148.6 in³ Rated Engine Speed 2000 rpm 2600 rpm Engine Power (Gross) 45 hp 48.8 hp PTO Power 38 hp Mech: 40.7 hp; HST: 38.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Electronically controlled high-pressure common rail Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Two gear-type pumps for steering and 3-point/remotes Implement Flow Not Published 12.6 gpm Steering Flow Not Published 7.0 gpm Total Hydraulic Flow 15.7 gpm 19.6 gpm (12.6 + 7.0, computed) Overall Hydraulic Pump Flow 15.7 gpm 19.6 gpm (12.6 + 7.0, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 14 gal Coolant Capacity 4 gal Not Published Crankcase Capacity 2.5 gal Not Published Transmission / Hydraulic System Capacity 10.5 gal Not Published Front Axle Fluid Capacity 4WD: 1.5 gal differential, plus 0.23 gal per wheel end Not Published ▶ PTO & HitchPTO Type Live Independent with SoftStart electronic modulation PTO Rear 540 rpm, 6-spline 540 rpm (1-3/8 in) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity 3,747 lb 2,645 lb Hitch Lift Capacity (at 24”) 2,204 lb 2,425 lb Lift Control Type Draft, position and response control Not Published ▶ Transmission & DrivetrainTransmission Type 8F x 2R SideShift sliding gear 8x8 synchro shuttle or 3-range hydrostatic No. of Speeds 8 forward and 2 reverse Mech: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dual dry Not Published Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering with separate reservoir Power steering Brakes Drum brakes Wet disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Spring-cushioned seat Front Axle Type 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Solid cast front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 138 in; 4WD: 139 in 132.8 in Overall Width 64.6 in 70.1 in Wheelbase 2WD: 80.7 in; 4WD: 81.5 in Not Published Ground Clearance Not Published 15 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 90.6 in 103.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2WD: 4,597 lb; 4WD: 4,927 lb 3,858 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD standard (ag): 6x16 front, 12.4x28 rear; 2WD optional (ag): 7.5x16 front, 13.6x28 rear; 4WD standard (ag): 10.5/80-18 front, 12.4x28 rear Not Published R1 Agricultural - Front 2WD: 6x16 (7.5x16 optional); 4WD: 10.5/80-18 Not Published R1 Agricultural - Rear 2WD: 12.4x28 (13.6x28 optional); 4WD: 12.4x28 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling FLx2813: skid steer quick attach; FLx2815: pin-type or skid steer Loader Model FLx2815 (2WD); 911X (4WD) FLx2813; FLx2815 Loader Lift Height FLx2815: 111 in; 911X: 114 in 111 in (FLx2813 and FLx2815 loaders) Loader Lift Capacity (Full Height) FLx2815: 2,810 lb; 911X: 2,470 lb FLx2813: 3,016 lb; FLx2815: 2,810 lb Loader Breakout Force FLx2815: 4,240 lb; 911X: 2,755 lb FLx2813: 4,176 lb; FLx2815: 4,240 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
