▶ EngineEngine Manufacturer Simpson LS Mtron Engine Model SJV326 L3C19-T Engine Type 3-cylinder, turbocharged, intercooled Diesel, 3-cylinder, turbocharged No. of Cylinders 3 3 Displacement 157.9 in³ 115.9 in³ Rated Engine Speed 2000 rpm 2600 rpm Engine Power (Gross) 55 hp 55 hp PTO Power 45.3 hp 44 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Replaceable dry element Fuel System Electronically controlled high-pressure common rail Common rail direct injection Alternator Not Published 70 A ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Not Published Implement Flow Not Published 8.2 gpm Steering Flow Not Published 5.3 gpm Total Hydraulic Flow 15.7 gpm 13.5 gpm (8.2 + 5.3, computed) Overall Hydraulic Pump Flow 15.7 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves One 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 14.5 gal Non-cab: 10.5 gal; Cab: 12.4 gal Coolant Capacity 4 gal Not Published Crankcase Capacity 2.5 gal Not Published Transmission / Hydraulic System Capacity 10.5 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Live Independent rear PTO, electro-hydraulic engagement PTO Rear 540 rpm, 6-spline 540 rpm Mid-PTO Availability Not Published Optional, 2000 rpm Category, 3-Point Hitch Category I and II Category I Hitch Lift Capacity 4,519 lb Not Published Hitch Lift Capacity (at 24”) 2,755 lb 2,756 lb Lift Control Type Draft, position and response control Mechanical draft control (MDC) ▶ Transmission & DrivetrainTransmission Type 8F x 2R SideShift sliding gear 3-range hydrostatic (HST) No. of Speeds 8 forward and 2 reverse Infinitely variable, 3 ranges Max Travel Speed (Forward) Not Published 17.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Applicable Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic steering with separate reservoir Power steering Brakes Oil-immersed wet disc Wet multi-disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Adjustable suspension seat Front Axle Type Straight adjustable (2WD) Mechanical Front Drive (MFD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 69.1 in Wheelbase 80.7 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 91.3 in 97.1 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model Not Published Not Applicable Overall Length 138 in 128.1 in ▶ WeightTractor Weight (Base) 4,894 lb Non-cab: 3,770 lb; Cab: 4,453 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard (ag): 6.00x16 front, 13.6x28 rear; optional (ag): 7.5x16 front, 16.6x28 rear R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 6.00x16 (7.5x16 optional) 9.5-16 R1 Agricultural - Rear 13.6x28 (16.6x28 optional) 13.6-24 R3 Turf - Front Not Published 28x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 12-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling Quick-Attach faceplate Loader Model FLx2815 L360A Loader Lift Height FLx2815: 111 in; 911X: 114 in 112 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb (at pivot pin); 911X: 2,470 lb (at pivot pins) 1,830 lb at 31.5 in. forward of pivot pin (L360A) Loader Breakout Force FLx2815: 4,240 lb (at pivot pin) 3,114 lbf ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Basic 2 years; powertrain 4 additional years
