▶ EngineEngine Manufacturer Simpson KIOTI Engine Model SJV326 3F183T Engine Type 3-cylinder, turbocharged, intercooled 3-cylinder, in-line vertical, water-cooled, 4-cycle, turbocharged, common rail diesel No. of Cylinders 3 3 Displacement 157.9 in³ 111.4 in³ Rated Engine Speed 2000 rpm 2600 rpm Engine Power (Gross) 55 hp 55 hp PTO Power 45.3 hp 46 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Dry type element Fuel System Electronically controlled high-pressure common rail Common Rail Diesel (CRDI) Alternator Not Published Not Published ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Gear Implement Flow Not Published Not Published Steering Flow Not Published Not Published Total Hydraulic Flow 15.7 gpm 16.5 gpm Overall Hydraulic Pump Flow 15.7 gpm 16.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves One 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 14.8 gal Coolant Capacity 4 gal 2.0 gal Crankcase Capacity 2.5 gal 1.58 gal Transmission / Hydraulic System Capacity 10.5 gal 14.53 gal Front Axle Fluid Capacity Not Published 1.8 gal ▶ PTO & HitchPTO Type Live Independent PTO Rear 540 rpm, 6-spline 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I and II Category I Hitch Lift Capacity 4,519 lb 3,538 lb Hitch Lift Capacity (at 24”) 2,755 lb 3,177 lb Lift Control Type Draft, position and response control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type 8F x 2R SideShift sliding gear Synchro Shuttle No. of Speeds 8 forward and 2 reverse 24x24 Max Travel Speed (Forward) Not Published 17.35 mph Max Travel Speed (Reverse) Not Published 15.42 mph Clutch Not Published Dry Type Single Stage Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic steering with separate reservoir Hydrostatic Power Steering Brakes Oil-immersed wet disc Wet Multi Disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Adjustable Seat Front Axle Type Straight adjustable (2WD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 65.7 in Wheelbase 80.7 in 75.6 in Ground Clearance Not Published 15.7 in Min. Turn Radius without Brakes Not Published 10.0 ft Height to Top of ROPS 91.3 in 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 138 in 139.6 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 4,894 lb 4,209 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard (ag): 6.00x16 front, 13.6x28 rear; optional (ag): 7.5x16 front, 16.6x28 rear Agricultural, Turf, Industrial R1 Agricultural - Front 6.00x16 (7.5x16 optional) 9.5-16 R1 Agricultural - Rear 13.6x28 (16.6x28 optional) 16.9-24 R3 Turf - Front Not Published 29-12.5-15 R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 17.5-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model FLx2815 KL6010 Loader Lift Height FLx2815: 111 in; 911X: 114 in KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) FLx2815: 2,810 lb (at pivot pin); 911X: 2,470 lb (at pivot pins) KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force FLx2815: 4,240 lb (at pivot pin) KL6010: 2,990 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Non-commercial: basic 2 years, powertrain 72 months, unlimited hours, parts and labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
