▶ EngineEngine Manufacturer Simpson Shibaura Engine Model SJV326 N4LDI-TA Engine Type 3-cylinder, turbocharged, intercooled 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 4 Displacement 157.9 in³ 135.2 in³ Rated Engine Speed 2000 rpm 2600 rpm Engine Power (Gross) 55 hp 57.3 hp PTO Power 45.3 hp Gear: 48.7 hp; HST: 45.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Primary and secondary elements Fuel System Electronically controlled high-pressure common rail Electronically controlled high-pressure common rail Alternator Not Published 90 A ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Gear-type single pump Implement Flow Not Published Not Published Steering Flow Not Published Not Published Total Hydraulic Flow 15.7 gpm 12.4 gpm Overall Hydraulic Pump Flow 15.7 gpm 12.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves One None No. of Optional Remote Valves Not Published 1 factory-installed; up to 3 field-installed ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 14 gal Coolant Capacity 4 gal 1.66 gal Crankcase Capacity 2.5 gal 1.53 gal Transmission / Hydraulic System Capacity 10.5 gal 10.04 gal Front Axle Fluid Capacity Not Published 2.21 gal ▶ PTO & HitchPTO Type Live Independent, electro-hydraulically engaged PTO Rear 540 rpm, 6-spline 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published No mid-PTO Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity 4,519 lb Not Published Hitch Lift Capacity (at 24”) 2,755 lb 2,425 lb Lift Control Type Draft, position and response control Not Published ▶ Transmission & DrivetrainTransmission Type 8F x 2R SideShift sliding gear Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST No. of Speeds 8 forward and 2 reverse Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Dry single-disc Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Mechanical engagement (Gear: right-side heel pedal; HST: left-side heel pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic steering with separate reservoir Power steering Brakes Oil-immersed wet disc Internal wet brakes, 2 pedals (Gear: right-hand; HST: left-hand) Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Suspended vinyl seat with retractable seatbelt Front Axle Type Straight adjustable (2WD) Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 74 in Wheelbase 80.7 in 78 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 91.3 in 104 in Height to Top of ROPS (folded) Not Published 80 in Height to Top of Cab Model Not Published Not Published Overall Length 138 in 133 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 4,894 lb Gear: 3,847 lb; HST: 3,891 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard (ag): 6.00x16 front, 13.6x28 rear; optional (ag): 7.5x16 front, 16.6x28 rear R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear R1 Agricultural - Front 6.00x16 (7.5x16 optional) 9.5x16 R1 Agricultural - Rear 13.6x28 (16.6x28 optional) 13.6x28; 16.9x24 R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling L135E: optional skid steer tool carrier Loader Model FLx2815 L135E Loader Lift Height FLx2815: 111 in; 911X: 114 in L135E: 110.2 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb (at pivot pin); 911X: 2,470 lb (at pivot pins) L135E: 2,430 lb (at pivot pin) Loader Breakout Force FLx2815: 4,240 lb (at pivot pin) L135E: 2,870 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
