▶ EngineEngine Manufacturer Simpson John Deere Engine Model SJV326 PowerTech 3029H Engine Type 3-cylinder, turbocharged, intercooled, liquid-cooled diesel Diesel, turbocharged, liquid-cooled No. of Cylinders 3 3 Displacement 157.9 in³ 179 in³ Rated Engine Speed 2000 rpm 2100 rpm Engine Power (Gross) 65 hp 65 hp PTO Power 55 hp 48.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Two paper elements Fuel System Electronically controlled high-pressure common rail Not Published Alternator Not Published 40 A ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Not Published Implement Flow Not Published 11.4 gpm Steering Flow Not Published 6.8 gpm Total Hydraulic Flow 15.7 gpm 18.2 gpm Overall Hydraulic Pump Flow 15.7 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 14.5 gal OOS: 18.0 gal; Cab: 21.6 gal Coolant Capacity 4 gal Not Published Crankcase Capacity 2.5 gal 9 qt Transmission / Hydraulic System Capacity 10.5 gal 2WD: 10 gal; 4WD: 10.3 gal Front Axle Fluid Capacity 4WD: 1.5 gal differential, plus 0.23 gal per wheel end 4.8 qt ▶ PTO & HitchPTO Type Independent OOS: Independent, mechanical actuation; Cab: Independent, mechanical or electrohydraulic actuation PTO Rear 540 rpm, 6-spline 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category 2, convertible to 1 Hitch Lift Capacity 4,519 lb Not Published Hitch Lift Capacity (at 24”) 2,755 lb 3,192 lb Lift Control Type Draft, position and response control Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type 8F x 8R synchro shuttle SyncShuttle (standard); PowrReverser (optional) No. of Speeds 8 forward and 8 reverse 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Split torque clutch Dry (SyncShuttle); Dry/Wet with 12F/12R PowrReverser Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Rear diff lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering with separate reservoir Power steering Brakes Oil-immersed wet disc Hydraulic wet disc brakes Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Not Published Front Axle Type 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 138 in; 4WD: 139 in 137.8 in Overall Width 69.9 in 57.3 in Wheelbase 2WD: 80.7 in; 4WD: 81.5 in 80.7 in Ground Clearance Not Published 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes Not Published 138 in Height to Top of ROPS 93.9 in 98.4 in Height to Top of ROPS (folded) Not Published 78.5 in Height to Top of Cab Model Not Published 95.6 in ▶ WeightTractor Weight (Base) 2WD: 5,115 lb; 4WD: 5,710 lb 2WD: 4,634 lb; MFWD: 5,621 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 7,165 lb ▶ Tire OptionsTire Size & Options 2WD standard (ag): 7.5x16 front, 14.9x28 rear; 4WD standard (ag): 9.5x24 front, 14.9x28 rear; industrial: 11L15 front (2WD) or 10.8/80-18 front (4WD) with 14.9x24 rear, or 12.5/80-18 front with 16.9x24 rear (4WD) Not Published R1 Agricultural - Front 2WD: 7.5x16; 4WD: 9.5x24 2WD: 7.5-16; MFWD: 9.5-24 R1 Agricultural - Rear 14.9x28 (2WD and 4WD) 16.9-28 R3 Turf - Front Not Published 9.5-16 (4WD) R3 Turf - Rear Not Published 21.5L-16.1 R4 Industrial - Front 2WD: 11L15; 4WD: 10.8/80-18 or 12.5/80-18 12.5-80-18 (4WD) R4 Industrial - Rear 14.9x24 or 16.9x24 (4WD) 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling H240 (NSL or MSL) Loader Model FLx2815 (2WD); 911X (4WD) H240NSL Loader Lift Height FLx2815: 111 in; 911X: 114 in 131 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb; 911X: 2,470 lb 3,671 lb Loader Breakout Force FLx2815: 4,240 lb; 911X: 2,755 lb 4,504 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
