▶ EngineEngine Manufacturer Simpson Mahindra Engine Model SJV326 Not Published Engine Type 3-cylinder, turbocharged, intercooled Turbocharged and intercooled, direct injection diesel No. of Cylinders 3 3 Displacement 157.9 in³ 161.5 in³ Rated Engine Speed 2000 rpm 2300 rpm Engine Power (Gross) 65 hp 65 hp PTO Power 54.2 hp 49.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Electronically controlled high-pressure common rail Turbocharged and intercooled, direct injection Alternator Not Published 90 A, 12 V ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Not Published Implement Flow Not Published 11 gpm Steering Flow Not Published 5.4 gpm Total Hydraulic Flow 15.7 gpm 16.4 gpm (11 + 5.4, computed) Overall Hydraulic Pump Flow 15.7 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 18.5 gal Coolant Capacity 4 gal Not Published Crankcase Capacity 2.5 gal Not Published Transmission / Hydraulic System Capacity 10.5 gal Not Published Front Axle Fluid Capacity 4WD: 1.5 gal differential, plus 0.23 gal per wheel end Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm, 6-spline 540 rpm @ 2300 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II CAT II with telescoping stabilizers and flex link ends Hitch Lift Capacity 4,519 lb 3,527 lb Hitch Lift Capacity (at 24”) 2,755 lb Not Published Lift Control Type Draft, position and response control Position and draft control ▶ Transmission & DrivetrainTransmission Type 8F x 8R synchro shuttle Synchro shuttle with partial synchromesh No. of Speeds 8 forward and 8 reverse 12F/12R Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Split torque clutch Single plate, dry Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic steering with separate reservoir Hydrostatic power steering, tilt Brakes Oil-immersed wet disc Wet disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Adjustable suspension seat Front Axle Type 2WD: straight adjustable; 4WD: planetary reduction Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 69.9 in 71.5 in Wheelbase 2WD: 80.7 in; 4WD: 81.5 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 12.5 ft Height to Top of ROPS 93.9 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 99.2 in Overall Length 2WD: 138 in; 4WD: 139 in 142 in ▶ WeightTractor Weight (Base) 2WD: 5,115 lb; 4WD: 5,710 lb 5,070 lb (2565 Shuttle Cab, operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD standard (ag): 7.5x16 front, 14.9x28 rear; 4WD standard (ag): 9.5x24 front, 14.9x28 rear; industrial: 11L15 front (2WD) or 10.8/80-18 front (4WD) with 14.9x24 rear, or 12.5/80-18 front with 16.9x24 rear (4WD) Ag, Industrial, Turf R1 Agricultural - Front 2WD: 7.5x16; 4WD: 9.5x24 9.5x20 R1 Agricultural - Rear 14.9x28 (2WD and 4WD) 14.9x28 R3 Turf - Front Not Published LSW305-521 R3 Turf - Rear Not Published LSW570-648 R4 Industrial - Front 2WD: 11L15; 4WD: 10.8/80-18 or 12.5/80-18 10.5/80x18 R4 Industrial - Rear 14.9x24 or 16.9x24 (4WD) 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling Not Published Loader Model FLx2815 (2WD); 911X (4WD) 2565CL Loader Lift Height FLx2815: 111 in; 911X: 114 in 2565CL: 115.4 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb (at pivot pin); 911X: 2,470 lb (at pivot pins) 2565CL: 3,122 lb (at pivot pin) Loader Breakout Force FLx2815: 4,240 lb (at pivot pin) 2565CL: 5,225 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 7-year limited powertrain warranty
