▶ EngineEngine Manufacturer Simpson FPT Engine Model SJV326 Not Published Engine Type 3-cylinder, turbocharged, intercooled, liquid-cooled diesel 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final No. of Cylinders 3 3 Displacement 157.9 in³ 178.8 in³ Rated Engine Speed 2000 rpm 2300 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 64 hp 60 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Electronically controlled high-pressure common rail Electronic high pressure common rail Alternator Not Published 120 A ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Fixed displacement Implement Flow Not Published 12.6 gpm Steering Flow Not Published Not Published Total Hydraulic Flow 15.7 gpm Not Published Overall Hydraulic Pump Flow 15.7 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 21.7 gal Coolant Capacity 4 gal Not Published Crankcase Capacity 2.5 gal Not Published Transmission / Hydraulic System Capacity 10.5 gal Not Published Front Axle Fluid Capacity 4WD: 1.5 gal differential, plus 0.23 gal per wheel end Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm, 6-spline 540 (standard); 540/540E (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category 1/2 Hitch Lift Capacity 4,519 lb 5,952 lb (optional hitch 6,614 lb) Hitch Lift Capacity (at 24”) 2,755 lb 4,300 lb (optional hitch 4,740 lb) Lift Control Type Draft, position and response control Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type 8F x 8R synchro shuttle MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 power shuttle (wet clutch); optional 12x12 with creeper (20x20) No. of Speeds 8 forward and 8 reverse MFD: 12F/12R; 2WD: 8F/8R; optional 20F/20R creeper Max Travel Speed (Forward) Not Published 18.6 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Split torque clutch MFD: wet clutch (12x12 power shuttle); 2WD: wet clutch (8x8 power shuttle) Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering with separate reservoir Hydrostatic Brakes Oil-immersed wet disc Wet disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column Mechanical contoured seat, adjustable; optional air-ride seat Front Axle Type 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 138 in; 4WD: 139 in 155.3 in Overall Width 72.9 in Not Published Wheelbase 2WD: 80.7 in; 4WD: 81.5 in 2WD: 82.1 in; MFD: 83.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 94.5 in Not Published Height to Top of ROPS (folded) Not Published 67.7 in Height to Top of Cab Model Not Published 2WD: 98 in; MFD: 100 in ▶ WeightTractor Weight (Base) 2WD: 5,269 lb; 4WD: 5,864 lb 2WD Cab: 6,173 lb; 2WD Non-cab: 5,622 lb; MFD Cab: 6,834 lb; MFD Non-cab: 6,283 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD standard (ag): 7.5x16 front, 16.9x28 rear; 4WD standard (ag): 9.5x24 front, 16.9x28 rear; industrial: 2WD 11L15 front with 14.9x24 rear; 4WD 12.5/80-18 front with 16.9x24 rear R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural - Front 2WD: 7.5x16; 4WD: 9.5x24 2WD: 9.5L-15; MFD: 11.2x24 R1 Agricultural - Rear 16.9x28 (2WD and 4WD) 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 2WD: 11L15; 4WD: 12.5/80-18 Not Published R4 Industrial - Rear 2WD: 14.9x24; 4WD: 16.9x24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling Not Published Loader Model FLx2815 (2WD); 911X (4WD) L610 Loader Lift Height FLx2815: 111 in; 911X: 114 in 130.3 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb; 911X: 2,470 lb NSL: 1,828 lb; MSL: 3,153 lb Loader Breakout Force FLx2815: 4,240 lb; 911X: 2,755 lb Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
