▶ EngineEngine Manufacturer Simpson Simpson Engine Model SJV326 SJV326 Engine Type 3-cylinder, turbocharged, intercooled, liquid-cooled diesel 3-cylinder, turbocharged, intercooled, liquid-cooled diesel No. of Cylinders 3 3 Displacement 157.9 in³ 157.9 in³ Rated Engine Speed 2000 rpm 2000 rpm Engine Power (Gross) 74 hp 65 hp PTO Power 64 hp 55 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Electronically controlled high-pressure common rail Electronically controlled high-pressure common rail Alternator Not Published Not Published ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Mark 1A scotch yoke piston pump Implement Flow Not Published Not Published Steering Flow Not Published Not Published Total Hydraulic Flow 15.7 gpm 15.7 gpm Overall Hydraulic Pump Flow 15.7 gpm 15.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm 10.6 gpm No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 14.5 gal Coolant Capacity 4 gal 4 gal Crankcase Capacity 2.5 gal 2.5 gal Transmission / Hydraulic System Capacity 10.5 gal 10.5 gal Front Axle Fluid Capacity 4WD: 1.5 gal differential, plus 0.23 gal per wheel end 4WD: 1.5 gal differential, plus 0.23 gal per wheel end ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm, 6-spline 540 rpm, 6-spline Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity 4,519 lb 4,519 lb Hitch Lift Capacity (at 24”) 2,755 lb 2,755 lb Lift Control Type Draft, position and response control Draft, position and response control ▶ Transmission & DrivetrainTransmission Type 8F x 8R synchro shuttle 8F x 8R synchro shuttle No. of Speeds 8 forward and 8 reverse 8 forward and 8 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Split torque clutch Split torque clutch Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Mechanical engagement via right-side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering with separate reservoir Hydrostatic power steering with separate reservoir Brakes Oil-immersed wet disc Oil-immersed wet disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column ReverseRise adjustable seat with fixed steering column Front Axle Type 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 138 in; 4WD: 139 in 2WD: 138 in; 4WD: 139 in Overall Width 72.9 in 69.9 in Wheelbase 2WD: 80.7 in; 4WD: 81.5 in 2WD: 80.7 in; 4WD: 81.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 94.5 in 93.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2WD: 5,269 lb; 4WD: 5,864 lb 2WD: 5,115 lb; 4WD: 5,710 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD standard (ag): 7.5x16 front, 16.9x28 rear; 4WD standard (ag): 9.5x24 front, 16.9x28 rear; industrial: 2WD 11L15 front with 14.9x24 rear; 4WD 12.5/80-18 front with 16.9x24 rear 2WD standard (ag): 7.5x16 front, 14.9x28 rear; 4WD standard (ag): 9.5x24 front, 14.9x28 rear; industrial: 11L15 front (2WD) or 10.8/80-18 front (4WD) with 14.9x24 rear, or 12.5/80-18 front with 16.9x24 rear (4WD) R1 Agricultural - Front 2WD: 7.5x16; 4WD: 9.5x24 2WD: 7.5x16; 4WD: 9.5x24 R1 Agricultural - Rear 16.9x28 (2WD and 4WD) 14.9x28 (2WD and 4WD) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 2WD: 11L15; 4WD: 12.5/80-18 2WD: 11L15; 4WD: 10.8/80-18 or 12.5/80-18 R4 Industrial - Rear 2WD: 14.9x24; 4WD: 16.9x24 14.9x24 or 16.9x24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling Skid steer style coupling Loader Model FLx2815 (2WD); 911X (4WD) FLx2815 (2WD); 911X (4WD) Loader Lift Height FLx2815: 111 in; 911X: 114 in FLx2815: 111 in; 911X: 114 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb; 911X: 2,470 lb FLx2815: 2,810 lb; 911X: 2,470 lb Loader Breakout Force FLx2815: 4,240 lb; 911X: 2,755 lb FLx2815: 4,240 lb; 911X: 2,755 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
