▶ EngineEngine Manufacturer Simpson Deutz Engine Model SJV326 TCD2.9 L4 Engine Type 3-cylinder, turbocharged, intercooled Turbocharged No. of Cylinders 3 4 Displacement 157.9 in³ 177.0 in³ Rated Engine Speed 2000 rpm 2200 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 63 hp 64.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Electronically controlled high-pressure common rail Common Rail Direct Injection Alternator Not Published 95 A, 12 V ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Not Published Implement Flow Not Published 10.3 gpm Steering Flow Not Published 5.8 gpm Total Hydraulic Flow 15.7 gpm 16.1 gpm Overall Hydraulic Pump Flow 15.7 gpm 16.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 23.8 gal Coolant Capacity 4 gal 10.6 qt Crankcase Capacity 2.5 gal 8.5 qt Transmission / Hydraulic System Capacity 10.5 gal 18.0 gal Front Axle Fluid Capacity 4WD: 1.5 gal differential, plus 0.23 gal per wheel end 17.4 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm, 6-spline 540/750 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Category I and II Category II Hitch Lift Capacity 4,519 lb 5,115 lb Hitch Lift Capacity (at 24”) 2,755 lb 3,414 lb Lift Control Type Draft, position and response control Position / Draft / Mechanical ▶ Transmission & DrivetrainTransmission Type 8F x 8R synchro shuttle RK74 Power Shuttle Cab (RK74PSC): 16F/16R power shuttle with creeper; RK74 Shuttle Shift Cab: 16F/16R synchronized shuttle with creeper No. of Speeds 8 forward and 8 reverse 16 forward, 16 reverse (creeper interlock) Max Travel Speed (Forward) Not Published 18.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Split torque clutch Single plate dry clutch (11.81 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Hydrostatic steering with separate reservoir Hydrostatic power steering Brakes Oil-immersed wet disc Wet disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column High-back suspension seat with extension Front Axle Type 2WD: straight adjustable; 4WD: planetary reduction Center-pivot, reverse Eliot type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 72.9 in 76.4 in Wheelbase 2WD: 80.7 in; 4WD: 81.5 in 86.1 in Ground Clearance Not Published 18.3 in Min. Turn Radius without Brakes Not Published 162.8 in Height to Top of ROPS 94.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 103.3 in Overall Length 2WD: 138 in; 4WD: 139 in 157.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2WD: 5,269 lb; 4WD: 5,864 lb 6,052 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD standard (ag): 7.5x16 front, 16.9x28 rear; 4WD standard (ag): 9.5x24 front, 16.9x28 rear; industrial: 2WD 11L15 front with 14.9x24 rear; 4WD 12.5/80-18 front with 16.9x24 rear Titan (USA): R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt) R1 Agricultural - Front 2WD: 7.5x16; 4WD: 9.5x24 11.2-24 R1 Agricultural - Rear 16.9x28 (2WD and 4WD) 16.9-30 R3 Turf - Front Not Published 12.0-20.5 R3 Turf - Rear Not Published 22.4-25.5 R4 Industrial - Front 2WD: 11L15; 4WD: 12.5/80-18 15-19.5 R4 Industrial - Rear 2WD: 14.9x24; 4WD: 16.9x24 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling L135SL: Skid-steer compatible quick coupler, self-leveling Loader Model FLx2815 (2WD); 911X (4WD) L135SL Loader Lift Height FLx2815: 111 in; 911X: 114 in L135SL: 135.5 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb (at pivot pin); 911X: 2,470 lb (at pivot pins) L135SL: 3,223 lb at pivot pin to full height Loader Breakout Force FLx2815: 4,240 lb (at pivot pin) L135SL: 5,335 lb at pivot pin ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Government and non-institutional: basic 24 months or 2,000 hours, powertrain 60 months or 3,000 hours; all other use: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
