▶ EngineEngine Manufacturer Simpson Deutz Engine Model SJV326 Deutz TCD2.9 L4 Engine Type 3-cylinder, turbocharged, intercooled, liquid-cooled diesel Turbocharged No. of Cylinders 3 4 Displacement 157.9 in³ 177.0 in³ Rated Engine Speed 2000 rpm 2200 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 64 hp 64.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Not Published Air Cleaner Not Published Not Published Fuel System Electronically controlled high-pressure common rail Common Rail Direct Injection Alternator Not Published 95 A, 12 V ▶ HydraulicsPump Type Mark 1A scotch yoke piston pump Not Published Implement Flow Not Published 10.3 gpm Steering Flow Not Published 5.8 gpm Total Hydraulic Flow 15.7 gpm 16.1 gpm Overall Hydraulic Pump Flow 15.7 gpm Not Published Hydraulic System Type Open center open center Rear Remote Hydraulic Flow 10.6 gpm Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 14.5 gal 23.8 gal Coolant Capacity 4 gal 10.6 qt Crankcase Capacity 2.5 gal 8.5 qt Transmission / Hydraulic System Capacity 10.5 gal 18.0 gal Front Axle Fluid Capacity 4WD: 1.5 gal differential, plus 0.23 gal per wheel end 17.4 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm, 6-spline 540/750 rpm Mid-PTO Availability Not Published No mid-PTO (N/A) Category, 3-Point Hitch Category I and II Category 2 Hitch Lift Capacity 4,519 lb 5,115 lb Hitch Lift Capacity (at 24”) 2,755 lb 3,418 lb Lift Control Type Draft, position and response control Position/Draft/Mech ▶ Transmission & DrivetrainTransmission Type 8F x 8R synchro shuttle 16F/16R Power Shuttle w/creeper No. of Speeds 8 forward and 8 reverse 16F/16R Max Travel Speed (Forward) Not Published 18.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Split torque clutch Dry Single Differential Lock & Limited Slip Options Mechanical engagement via right-side heel pedal Differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering with separate reservoir Hydrostatic Brakes Oil-immersed wet disc Wet Disc Seat Suspension & Adjustability ReverseRise adjustable seat with fixed steering column High-back suspension seat with extension Front Axle Type 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 138 in; 4WD: 139 in 157.5 in Overall Width 72.9 in 76.4 in Wheelbase 2WD: 80.7 in; 4WD: 81.5 in 86.1 in Ground Clearance Not Published 18.3 in Min. Turn Radius without Brakes Not Published 162.8 in Height to Top of ROPS 94.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 103.3 in ▶ WeightTractor Weight (Base) 2WD: 5,269 lb; 4WD: 5,864 lb 6,052 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD standard (ag): 7.5x16 front, 16.9x28 rear; 4WD standard (ag): 9.5x24 front, 16.9x28 rear; industrial: 2WD 11L15 front with 14.9x24 rear; 4WD 12.5/80-18 front with 16.9x24 rear Titan Tire & Wheels: R1 Ag (Std), R3 Turf (Opt), R4 Industrial (Opt) R1 Agricultural - Front 2WD: 7.5x16; 4WD: 9.5x24 11.2x24 R1 Agricultural - Rear 16.9x28 (2WD and 4WD) 16.9x30 R3 Turf - Front Not Published 12.0x20.5 R3 Turf - Rear Not Published 22.4x25.5 R4 Industrial - Front 2WD: 11L15; 4WD: 12.5/80-18 15x9.5 R4 Industrial - Rear 2WD: 14.9x24; 4WD: 16.9x24 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style coupling Not Published Loader Model FLx2815 (2WD); 911X (4WD) L135SL Loader Lift Height FLx2815: 111 in; 911X: 114 in 135.5 in Loader Lift Capacity (Full Height) FLx2815: 2,810 lb; 911X: 2,470 lb 3,223 lb Loader Breakout Force FLx2815: 4,240 lb; 911X: 2,755 lb 5,335 lbf ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Engine and power transmission devices: 36 months or 2000 hours; other parts: 24 months or 1500 hours (Tractor Non-Rental & Non-Commercial use)
