▶ EngineEngine Manufacturer Shibaura KIOTI (Daedong) Engine Model N4LDI-T 4A200T Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Indirect injection, vertical, water-cooled, 4-cycle turbocharged diesel No. of Cylinders 4 4 Displacement 135.2 in³ 122 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.8 hp 49 hp PTO Power Gear: 41.4 hp; HST: 39 hp 41.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Primary and secondary elements Dual stage air filter cartridge Fuel System Electronically controlled high-pressure common rail Indirect injection Alternator 90 A 50 A, 12 V ▶ HydraulicsPump Type Gear-type single pump Not Published Implement Flow Not Published 9.9 gpm Steering Flow Not Published 4.3 gpm Total Hydraulic Flow 12.4 gpm 14.2 gpm Overall Hydraulic Pump Flow 12.4 gpm 14.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 1 No. of Optional Remote Valves 1 factory-installed; up to 3 field-installed Not Published ▶ Fluid CapacityFuel Tank Capacity 14 gal 10.6 gal Coolant Capacity 1.66 gal 9.4 qt Crankcase Capacity 1.53 gal 7.4 qt Transmission / Hydraulic System Capacity 10.04 gal 35.9 qt Front Axle Fluid Capacity 2.21 gal 8.6 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm Mid-PTO Availability No mid-PTO Not Published Category, 3-Point Hitch Category I and II Category I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,425 lb 2,828 lb Lift Control Type Not Published Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST Synchronized shuttle No. of Speeds Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 12F/12R Max Travel Speed (Forward) Not Published 15.84 mph Max Travel Speed (Reverse) Not Published 15.3 mph Clutch Dry single-disc Dry type single plate, single stage Differential Lock & Limited Slip Options Mechanical engagement (Gear: right side heel pedal; HST: left side heel pedal) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydraulic power steering Brakes Internal wet disc, 2 pedals (Gear: right hand; HST: left hand) Wet disc type Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt Adjustable seat Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives 4WD (MFWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133 in 130.8 in Overall Width 74 in 61.0 in Wheelbase 78 in 71.6 in Ground Clearance Not Published 14.5 in Min. Turn Radius without Brakes Not Published 125.2 in Height to Top of ROPS 104 in 88 in Height to Top of ROPS (folded) 80 in Not Published Height to Top of Cab Model Not Published 91 in ▶ WeightTractor Weight (Base) Gear: 3,836 lb; HST: 3,880 lb 3,813 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5x16 9.5-16 R1 Agricultural - Rear 13.6x28; 16.9x24 14.9-24 R3 Turf - Front 27x10.50-15 29x12.5-15 R3 Turf - Rear 44x18.00-20 21.5L-16.1 R4 Industrial - Front 10-16.5 12x16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System L135E: optional skid steer tool carrier Not Published Loader Model L135E KL1470; KL1590 Loader Lift Height L135E: 110.2 in KL1470: 111.44 in; KL1590: 121.06 in Loader Lift Capacity (Full Height) L135E: 2,430 lb KL1470: 2,100 lb; KL1590: 2,500 lb Loader Breakout Force L135E: 2,870 lb KL1470: 3,400 lb; KL1590: 4,000 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Limited: Tractors (Non-Commercial Application) 24 months parts & labor; Extended (driveline): 48 months parts & labor ▶ ITC Company AccessoriesAccessories that fit None tagged yet
