▶ EngineEngine Manufacturer Shibaura Kubota Engine Model N4LDI-T V2403-CR-E4-GL5 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated No. of Cylinders 4 4 Displacement 135.2 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.8 hp 49 hp PTO Power Gear: 41.4 hp; HST: 39 hp 39.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Primary and secondary elements Dry paper, dual element Fuel System Electronically controlled high-pressure common rail Electronic CRS (Common Rail System) Alternator 90 A 40 A, 12 V ▶ HydraulicsPump Type Gear-type single pump Tandem pump - gear type Implement Flow Not Published 9.4 gpm Steering Flow Not Published 4.7 gpm Total Hydraulic Flow 12.4 gpm 14.1 gpm Overall Hydraulic Pump Flow 12.4 gpm 14.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 None standard (up to 3 optional) No. of Optional Remote Valves 1 factory-installed; up to 3 field-installed Optional, up to 3 (double-acting valve or float detent valve options, any position) ▶ Fluid CapacityFuel Tank Capacity 14 gal 13.5 gal Coolant Capacity 1.66 gal 8.7 qt Crankcase Capacity 1.53 gal 8.7 qt Transmission / Hydraulic System Capacity 10.04 gal 11.4 gal Front Axle Fluid Capacity 2.21 gal 8.9 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Live independent (hydraulic clutch) PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm @ 2475 engine rpm Mid-PTO Availability No mid-PTO Optional Category, 3-Point Hitch Category I and II SAE Category 1 Hitch Lift Capacity Not Published 3,858 lb Hitch Lift Capacity (at 24”) 2,425 lb 2,756 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST Hydrostatic No. of Speeds Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.1 mph Clutch Dry single-disc Not Published Differential Lock & Limited Slip Options Mechanical engagement (Gear: right side heel pedal; HST: left side heel pedal) Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Internal wet disc, 2 pedals (Gear: right hand; HST: left hand) Wet disc type, mechanically activated Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133 in 129.5 in Overall Width 74 in 66.5 in Wheelbase 78 in 74.6 in Ground Clearance Not Published 14.4 in Min. Turn Radius without Brakes Not Published 8.9 ft (with brake applied) Height to Top of ROPS 104 in 97.6 in Height to Top of ROPS (folded) 80 in Not Published Height to Top of Cab Model Not Published Not Applicable ▶ WeightTractor Weight (Base) Gear: 3,836 lb; HST: 3,880 lb 3847 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear R1 Agricultural; R3 Turf (Option 1) or R3 LSW Turf (Option 2); R4 Industrial R1 Agricultural - Front 9.5x16 8.3-16 R1 Agricultural - Rear 13.6x28; 16.9x24 14.9-24 R3 Turf - Front 27x10.50-15 29x12.50-15 R3 Turf - Rear 44x18.00-20 44x18-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System L135E: optional skid steer tool carrier Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Model L135E LA1055 Loader Lift Height L135E: 110.2 in 112.7 in Loader Lift Capacity (Full Height) L135E: 2,430 lb 2361 lb Loader Breakout Force L135E: 2,870 lb 3171 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
