▶ EngineEngine Manufacturer Shibaura Daedong Engine Model N4LDI-T 4B243LW Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Indirect injection diesel No. of Cylinders 4 4 Displacement 135.2 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 48.8 hp 49 hp PTO Power Gear: 41.4 hp; HST: 39 hp 41.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Primary and secondary elements Not Published Fuel System Electronically controlled high-pressure common rail Indirect injection Alternator 90 A 50 A, 12 V ▶ HydraulicsPump Type Gear-type single pump Not Published Implement Flow Not Published 9.5 gpm Steering Flow Not Published 5 gpm Total Hydraulic Flow 12.4 gpm 14.5 gpm (9.5 + 5, computed) Overall Hydraulic Pump Flow 12.4 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None 1 No. of Optional Remote Valves 1 factory-installed; up to 3 field-installed 3 ▶ Fluid CapacityFuel Tank Capacity 14 gal 16 gal Coolant Capacity 1.66 gal Not Published Crankcase Capacity 1.53 gal Not Published Transmission / Hydraulic System Capacity 10.04 gal Not Published Front Axle Fluid Capacity 2.21 gal Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm @ 2600 rpm Mid-PTO Availability No mid-PTO Not Published Category, 3-Point Hitch Category I and II CAT I with check chains (5010 4WD Gear); CAT I with check chains (5010 Gear Cab); CAT I with telescopic check chains (5010 HST Cab) Hitch Lift Capacity Not Published 3,314 lb Hitch Lift Capacity (at 24”) 2,425 lb Not Published Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST Constant mesh (5010 4WD Gear); constant mesh (5010 Gear Cab); HST, 3 ranges (5010 HST Cab) No. of Speeds Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 9F/3R (5010 4WD Gear); 9F/3R (5010 Gear Cab); infinite, 3 ranges (5010 HST Cab) Max Travel Speed (Forward) Not Published 15.3 mph (5010 4WD Gear); 15.3 mph (5010 Gear Cab); 17.7 mph (5010 HST Cab) Max Travel Speed (Reverse) Not Published 9.2 mph (5010 4WD Gear); 9.2 mph (5010 Gear Cab); 17.7 mph (5010 HST Cab) Clutch Dry single-disc Single plate, dry (5010 4WD Gear); single plate, dry (5010 Gear Cab); n/a (5010 HST Cab) Differential Lock & Limited Slip Options Mechanical engagement (Gear: right-side heel pedal; HST: left-side heel pedal) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering, tilt Brakes Internal wet brakes, 2 pedals (Gear: right-hand; HST: left-hand) Wet disc Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt Adjustable suspension seat Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 74 in 71.1 in (5010 4WD Gear); 71.5 in (5010 Gear Cab); 71.5 in (5010 HST Cab) Wheelbase 78 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 11 ft Height to Top of ROPS 104 in 101 in Height to Top of ROPS (folded) 80 in Not Published Height to Top of Cab Model Not Published 98.4 in Overall Length 133 in (with 3-point hitch) 134 in (with industrial tires) ▶ WeightTractor Weight (Base) Gear: 3,836 lb; HST: 3,880 lb 3,836 lb (5010 4WD Gear, operating weight); 4,078 lb (5010 Gear Cab, operating weight); 4,078 lb (5010 HST Cab, operating weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear Ag, Industrial, Golf (turf) R1 Agricultural - Front 9.5x16 9.5x16 R1 Agricultural - Rear 13.6x28; 16.9x24 14.9x24 R3 Turf - Front 27x10.50-15 LSW305-521 R3 Turf - Rear 44x18.00-20 LSW570-648 R4 Industrial - Front 10-16.5 12x16.5 R4 Industrial - Rear 17.5L-24 16.9x24 ▶ Loader & AttachmentsQuick Attach Loader System L135E: optional skid steer tool carrier Not Published Loader Model L135E ML151 (5010 4WD Gear); ML156 (5010 Gear Cab, 5010 HST Cab) Loader Lift Height L135E: 110.2 in ML151: 115.4 in; ML156: 115.4 in Loader Lift Capacity (Full Height) L135E: 2,430 lb (at pivot pin) ML151: 3,122 lb; ML156: 3,122 lb Loader Breakout Force L135E: 2,870 lb ML151: 5,225 lb; ML156: 5,225 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year limited warranty
