▶ EngineEngine Manufacturer Shibaura John Deere Engine Model N4LDI-TA PowerTech 3029H Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Diesel, turbocharged, liquid-cooled No. of Cylinders 4 3 Displacement 135.2 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 57.3 hp 57 hp PTO Power Gear: 48.7 hp; HST: 45.9 hp 38.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Primary and secondary elements Two paper elements Fuel System Electronically controlled high-pressure common rail Not Published Alternator 90 A 40 A ▶ HydraulicsPump Type Gear-type single pump Not Published Implement Flow Not Published 11.4 gpm Steering Flow Not Published 6.8 gpm Total Hydraulic Flow 12.4 gpm 18.2 gpm Overall Hydraulic Pump Flow 12.4 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 1 No. of Optional Remote Valves 1 factory-installed; up to 3 field-installed 2 ▶ Fluid CapacityFuel Tank Capacity 14 gal OOS: 18.0 gal; Cab: 21.6 gal Coolant Capacity 1.66 gal 10 qt Crankcase Capacity 1.53 gal 9 qt Transmission / Hydraulic System Capacity 10.04 gal 10.3 gal Front Axle Fluid Capacity 2.21 gal 4.8 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged OOS: Independent, mechanical actuation; Cab: Independent, mechanical or electrohydraulic actuation PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm (540E optional with PowrReverser) Mid-PTO Availability No mid-PTO Not Published Category, 3-Point Hitch Category I and II Category 2, convertible to 1 Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,425 lb 3,192 lb Lift Control Type Not Published Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST SyncShuttle (standard); PowrReverser (optional) No. of Speeds Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single-disc Dry (SyncShuttle); Dry/Wet with 12F/12R PowrReverser Differential Lock & Limited Slip Options Mechanical engagement (Gear: right side heel pedal; HST: left side heel pedal) Rear diff lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Internal wet disc, 2 pedals (Gear: right hand; HST: left hand) Hydraulic wet disc brakes Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt Not Published Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133 in 137.8 in Overall Width 74 in 57.3 in Wheelbase 78 in 80.7 in Ground Clearance Not Published 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes Not Published 138 in Height to Top of ROPS 104 in 96.4 in Height to Top of ROPS (folded) 80 in 77.1 in Height to Top of Cab Model Not Published 94.3 in ▶ WeightTractor Weight (Base) Gear: 3,847 lb; HST: 3,891 lb 2WD: 4,524 lb; MFWD: 5,511 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 7,054 lb ▶ Tire OptionsTire Size & Options R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear Not Published R1 Agricultural - Front 9.5x16 2WD: 7.5-16; MFWD: 9.5-24 R1 Agricultural - Rear 13.6x28; 16.9x24 14.9-28 R3 Turf - Front 27x10.50-15 9.5-16 R3 Turf - Rear 44x18.00-20 21.5L-16.1 R4 Industrial - Front 10-16.5 12.5/80-18 R4 Industrial - Rear 17.5L-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System L135E: optional skid steer tool carrier H240 (NSL or MSL) Loader Model L135E H240NSL Loader Lift Height L135E: 110.2 in 131 in Loader Lift Capacity (Full Height) L135E: 2,430 lb 3,671 lb Loader Breakout Force L135E: 2,870 lb 4,504 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
