▶ EngineEngine Manufacturer Shibaura Kubota Engine Model N4LDI-TA V2403CR-T Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 4 4 Displacement 135.2 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 57.3 hp 57 hp PTO Power Gear: 48.7 hp; HST: 45.9 hp 46.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Primary and secondary elements Dry-dual element Fuel System Electronically controlled high-pressure common rail Common Rail System (CRS), direct injection Alternator 90 A 45 A, 12 V ▶ HydraulicsPump Type Gear-type single pump Gear Implement Flow Not Published 9.5 gpm Steering Flow Not Published 4.9 gpm Total Hydraulic Flow 12.4 gpm 14.4 gpm (9.5 + 4.9, computed) Overall Hydraulic Pump Flow 12.4 gpm 14.4 gpm (9.5 + 4.9, computed) Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None Not Published No. of Optional Remote Valves 1 factory-installed; up to 3 field-installed Maximum 3 (opt) ▶ Fluid CapacityFuel Tank Capacity 14 gal 13.5 gal Coolant Capacity 1.66 gal 6.9 qt Crankcase Capacity 1.53 gal 7.4 qt Transmission / Hydraulic System Capacity 10.04 gal 11.6 gal Front Axle Fluid Capacity 2.21 gal 8.9 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Live independent, hydraulic PTO with PTO brake, wet clutch PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm Mid-PTO Availability No mid-PTO Not Published Category, 3-Point Hitch Category I and II I & II Hitch Lift Capacity Not Published 2,870 lb Hitch Lift Capacity (at 24”) 2,425 lb 2,310 lb Lift Control Type Not Published Position (std), Draft (opt) ▶ Transmission & DrivetrainTransmission Type Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST 3-range hydrostatic (HST) No. of Speeds Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 3-range Max Travel Speed (Forward) Not Published DT (2WD/4WD): 17.3 mph; HST (4WD): 17.7 mph Max Travel Speed (Reverse) Not Published DT (2WD/4WD): 15.9 mph; HST (4WD): 16.0 mph Clutch Dry single-disc No clutch Differential Lock & Limited Slip Options Mechanical engagement (Gear: right-side heel pedal; HST: left-side heel pedal) Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Internal wet brakes, 2 pedals (Gear: right-hand; HST: left-hand) Mechanical wet disc Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt High-back suspension seat (optional arm rests) Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Bevel gear type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,650 lb ▶ Dimensions & ManeuverabilityOverall Width 74 in 69.7 in Wheelbase 78 in 74.6 in Ground Clearance Not Published 15.2 in Min. Turn Radius without Brakes Not Published 8.9 ft (with brake applied) Height to Top of ROPS 104 in 95.7 in Height to Top of ROPS (folded) 80 in Not Published Height to Top of Cab Model Not Published Not Applicable Overall Length 133 in (with 3-point hitch) 125.9 in (without 3-point hitch) ▶ WeightTractor Weight (Base) Gear: 3,847 lb; HST: 3,891 lb 3,734 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear Standard ag: 9.5-16 / 14.9-26 R1 Agricultural - Front 9.5x16 9.5-16 R1 Agricultural - Rear 13.6x28; 16.9x24 14.9-26 R3 Turf - Front 27x10.50-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System L135E: optional skid steer tool carrier 1065A: 2-Lever Quick Coupler for Loader Attachment Loader Model L135E LA1065 Loader Lift Height L135E: 110.2 in 111.2 in (at pivot pin) Loader Lift Capacity (Full Height) L135E: 2,430 lb (at pivot pin) 2,275 lb (at pivot pin) Loader Breakout Force L135E: 2,870 lb 3,102 lbf ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Residential: basic 24 months or 2,000 hours, powertrain 72 months or 3,000 hours; commercial: basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
