▶ EngineEngine Manufacturer Shibaura Shibaura Engine Model N4LDI-TA N4LDI-TA Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 4-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 4 4 Displacement 135.2 in³ 135.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 57.3 hp 59.9 hp PTO Power Gear: 48.7 hp; HST: 45.9 hp Mech: 46.1 hp; HST: 44.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Primary and secondary elements Dry Fuel System Electronically controlled high-pressure common rail Common rail direct injection Alternator 90 A Not Published ▶ HydraulicsPump Type Gear-type single pump Engine-driven gear-type pump Implement Flow Not Published Not Published Steering Flow Not Published Not Published Total Hydraulic Flow 12.4 gpm Not Published Overall Hydraulic Pump Flow 12.4 gpm 12x12 Power Shuttle: 12.7 gpm; HST: 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves None Not Published No. of Optional Remote Valves 1 factory-installed; up to 3 field-installed Up to 3 ▶ Fluid CapacityFuel Tank Capacity 14 gal 14 gal Coolant Capacity 1.66 gal 7.08 qt Crankcase Capacity 1.53 gal 6.87 qt Transmission / Hydraulic System Capacity 10.04 gal Power Shuttle: 11.35 gal; HST: 9.25 gal Front Axle Fluid Capacity 2.21 gal 9 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged Independent, with soft-start feature PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm (6-spline) Mid-PTO Availability No mid-PTO Optional, 2,000 rpm (not offered with the 12x12 power shuttle) Category, 3-Point Hitch Category I and II Category I with extendable ball ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 2,425 lb 12x12 Power Shuttle: 3,307 lb; HST: 3,086 lb Lift Control Type Not Published Draft control optional ▶ Transmission & DrivetrainTransmission Type Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 12 x 12 Power Shuttle (3 ranges, 4 gears); HST: 3-range, infinite speeds in each range Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single-disc Multiple stage wet type Differential Lock & Limited Slip Options Mechanical engagement (Gear: right-side heel pedal; HST: left-side heel pedal) Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Internal wet brakes, 2 pedals (Gear: right-hand; HST: left-hand) Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 74 in 12x12 Power Shuttle: 71.1 in; HST: 65.4 in Wheelbase 78 in 12x12 Power Shuttle: 80.3 in; HST: 77.9 in Ground Clearance Not Published 14.8 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 104 in 12x12 Power Shuttle: 103.2 in; HST: 102.4 in Height to Top of ROPS (folded) 80 in Not Published Height to Top of Cab Model Not Published 12x12 Power Shuttle: 93.3 in; HST: 92.9 in Overall Length 133 in (with 3-point hitch) HST: 132.3 in ▶ WeightTractor Weight (Base) Gear: 3,847 lb; HST: 3,891 lb 12x12 Power Shuttle: 4,233 lb (ROPS base weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear AG, Turf, Industrial, Snow R1 Agricultural - Front 9.5x16 9.5x16 R1 Agricultural - Rear 13.6x28; 16.9x24 16.9x26 R3 Turf - Front 27x10.50-15 27x10.50-15 R3 Turf - Rear 44x18.00-20 44x18.00-20 R4 Industrial - Front 10-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System L135E: optional skid steer tool carrier DL135: Skid steer quick attach Loader Model L135E DL135 Loader Lift Height L135E: 110.2 in DL135: 111 in (at pivot pin) Loader Lift Capacity (Full Height) L135E: 2,430 lb (at pivot pin) DL135: 2,610 lb (at pivot pin, full height) Loader Breakout Force L135E: 2,870 lb DL135: 4,000 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Five-year powertrain warranty
