▶ EngineEngine Manufacturer Shibaura Simpson Engine Model N4LDI-TA SJV326 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, turbocharged, intercooled, liquid-cooled diesel No. of Cylinders 4 3 Displacement 135.2 in³ 157.9 in³ Rated Engine Speed 2600 rpm 2000 rpm Engine Power (Gross) 57.3 hp 55 hp PTO Power Gear: 48.7 hp; HST: 45.9 hp 46 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Primary and secondary elements Not Published Fuel System Electronically controlled high-pressure common rail Electronically controlled high-pressure common rail Alternator 90 A Not Published ▶ HydraulicsPump Type Gear-type single pump Mark 1A scotch yoke piston pump Implement Flow Not Published Not Published Steering Flow Not Published Not Published Total Hydraulic Flow 12.4 gpm 15.7 gpm Overall Hydraulic Pump Flow 12.4 gpm 15.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 10.6 gpm No. of Standard Remote Valves 0 1 No. of Optional Remote Valves 1 factory-installed; up to 3 field-installed Not Published ▶ Fluid CapacityFuel Tank Capacity 14 gal 14.5 gal Coolant Capacity 1.66 gal 4 gal Crankcase Capacity 1.53 gal 2.5 gal Transmission / Hydraulic System Capacity 10.04 gal 10.5 gal Front Axle Fluid Capacity 2.21 gal 4WD: 1.5 gal differential, plus 0.23 gal per wheel end ▶ PTO & HitchPTO Type Independent, electro-hydraulically engaged 2WD: Live; 4WD: Independent PTO Rear 540 rpm (1-3/8 in 6-spline) 540 rpm, 6-spline Mid-PTO Availability No mid-PTO Not Published Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity Not Published 4,519 lb Hitch Lift Capacity (at 24”) 2,425 lb 2,755 lb Lift Control Type Not Published Draft, position and response control ▶ Transmission & DrivetrainTransmission Type Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST 2WD: 8F x 2R SideShift sliding gear; 4WD: 8F x 8R synchro shuttle No. of Speeds Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 2WD: 8 forward and 2 reverse; 4WD: 8 forward and 8 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single-disc 2WD: dual stage dry; 4WD: split torque Differential Lock & Limited Slip Options Mechanical engagement (Gear: right side heel pedal; HST: left side heel pedal) Mechanical engagement via right-side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering with separate reservoir Brakes Internal wet disc, 2 pedals (Gear: right hand; HST: left hand) Oil-immersed wet disc Seat Suspension & Adjustability Suspended vinyl seat with retractable seatbelt ReverseRise adjustable seat with fixed steering column Front Axle Type Cast steel 4WD front axle with center drive line and bevel-gear final drives 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133 in 2WD: 138 in; 4WD: 139 in Overall Width 74 in 66.5 in Wheelbase 78 in 2WD: 80.7 in; 4WD: 81.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 104 in 91.3 in Height to Top of ROPS (folded) 80 in Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) Gear: 3,847 lb; HST: 3,891 lb 2WD: 4,894 lb; 4WD: 5,394 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear 2WD standard (ag): 6.00x16 front, 13.6x28 rear; 2WD optional (ag): 7.5x16 front, 16.6x28 rear; 4WD standard (ag): 9.5x24 front, 14.9x28 rear; 4WD industrial: 10.5/80-18 front with 14.9x24 rear, or 12.5/80-18 front with 16.9x24 rear R1 Agricultural - Front 9.5x16 2WD: 6.00x16 (7.5x16 optional); 4WD: 9.5x24 R1 Agricultural - Rear 13.6x28; 16.9x24 2WD: 13.6x28 (16.6x28 optional); 4WD: 14.9x28 R3 Turf - Front 27x10.50-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 10-16.5 4WD: 10.5/80-18 or 12.5/80-18 R4 Industrial - Rear 17.5L-24 4WD: 14.9x24 or 16.9x24 ▶ Loader & AttachmentsQuick Attach Loader System L135E: optional skid steer tool carrier Skid steer style coupling Loader Model L135E FLx2815 (2WD); 911X (4WD) Loader Lift Height L135E: 110.2 in FLx2815: 111 in; 911X: 114 in Loader Lift Capacity (Full Height) L135E: 2,430 lb FLx2815: 2,810 lb; 911X: 2,470 lb Loader Breakout Force L135E: 2,870 lb FLx2815: 4,240 lb; 911X: 2,755 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
