▶ EngineEngine Manufacturer Iseki Kubota Engine Model Not Published V2403-CR-E5 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 4 4 Displacement 148.6 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.8 hp 48.4 hp PTO Power Mech: 40.7 hp; HST: 38.5 hp 39 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Dry type, primary and secondary element Fuel System Not Published Direct injection Alternator Not Published 45 A, 12 V ▶ HydraulicsPump Type Two gear-type pumps for steering and 3-point/remotes Not Published Implement Flow 12.6 gpm 7.8 gpm Steering Flow 7.0 gpm 4.7 gpm Total Hydraulic Flow 19.6 gpm (12.6 + 7.0, computed) 12.5 gpm (7.8 + 4.7, computed) Overall Hydraulic Pump Flow 19.6 gpm (12.6 + 7.0, computed) 12.5 gpm (7.8 + 4.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) ▶ Fluid CapacityFuel Tank Capacity 14 gal 13.5 gal Coolant Capacity Not Published 6.9 qt Crankcase Capacity Not Published 8.7 qt Transmission / Hydraulic System Capacity Not Published 10.6 gal Front Axle Fluid Capacity Not Published 6.9 qt ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Live independent PTO with hydraulic clutch PTO Rear 540 rpm (1-3/8 in) 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II SAE Category I Hitch Lift Capacity 2,645 lb 2,870 lb Hitch Lift Capacity (at 24”) 2,425 lb 2,320 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type 8x8 synchro shuttle or 3-range hydrostatic Hydrostatic transmission (3-range) No. of Speeds Mech: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 3-range Max Travel Speed (Forward) Not Published 15.8 mph Max Travel Speed (Reverse) Not Published 14.2 mph Clutch Not Published Not Applicable Differential Lock & Limited Slip Options Not Published Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Mechanical, wet disc type Seat Suspension & Adjustability Spring-cushioned seat Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Solid cast front axle Cast-iron front axle Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,430 lb ▶ Dimensions & ManeuverabilityOverall Width 70.1 in 62.2 in Wheelbase Not Published 72.6 in Ground Clearance 15 in 15.2 in Min. Turn Radius without Brakes Not Published 8.5 ft (with brake applied) Height to Top of ROPS 103.8 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 132.8 in 120.3 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,858 lb 3,549 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Agricultural; Turf; Industrial (R4) R1 Agricultural - Front Not Published 8.3-16 R1 Agricultural - Rear Not Published 14.9-24 R3 Turf - Front Not Published 27X10.5-15 R3 Turf - Rear Not Published 44X18-20 R4 Industrial - Front Not Published 10.0-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System FLx2813: skid steer quick attach LA766 2-Lever Quick Coupler Loader Model FLx2813 LA766 Loader Lift Height 111 in (FLx2813 loader) 105.2 in (at pivot pin) Loader Lift Capacity (Full Height) FLx2813: 3,016 lb (at pivot pin) 1,676 lb (at pivot pin, max. height) Loader Breakout Force FLx2813: 4,176 lb (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
