▶ EngineEngine Manufacturer Iseki Shibaura Engine Model Not Published N4LDI-T Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 148.6 in³ 135.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.8 hp 48.8 hp PTO Power Mech: 40.7 hp; HST: 38.5 hp Gear: 41.4 hp; HST: 39 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Primary and secondary elements Fuel System Not Published Electronically controlled high-pressure common rail Alternator Not Published 90 A ▶ HydraulicsPump Type Two gear-type pumps for steering and 3-point/remotes Gear-type single pump Implement Flow 12.6 gpm Not Published Steering Flow 7.0 gpm Not Published Total Hydraulic Flow 19.6 gpm (12.6 + 7.0, computed) 12.4 gpm Overall Hydraulic Pump Flow 19.6 gpm (12.6 + 7.0, computed) 12.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Not Published 1 factory-installed; up to 3 field-installed ▶ Fluid CapacityFuel Tank Capacity 14 gal 14 gal Coolant Capacity Not Published 1.66 gal Crankcase Capacity Not Published 1.53 gal Transmission / Hydraulic System Capacity Not Published 10.04 gal Front Axle Fluid Capacity Not Published 2.21 gal ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent, electro-hydraulically engaged PTO Rear 540 rpm (1-3/8 in) 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Not Published No mid-PTO Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity 2,645 lb Not Published Hitch Lift Capacity (at 24”) 2,425 lb 2,425 lb Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type 8x8 synchro shuttle or 3-range hydrostatic Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST No. of Speeds Mech: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Dry single-disc Differential Lock & Limited Slip Options Not Published Mechanical engagement (Gear: right side heel pedal; HST: left side heel pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Internal wet disc, 2 pedals (Gear: right hand; HST: left hand) Seat Suspension & Adjustability Spring-cushioned seat Suspended vinyl seat with retractable seatbelt Front Axle Type Solid cast front axle Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.8 in 133 in Overall Width 70.1 in 74 in Wheelbase Not Published 78 in Ground Clearance 15 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103.8 in 104 in Height to Top of ROPS (folded) Not Published 80 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,858 lb Gear: 3,836 lb; HST: 3,880 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear R1 Agricultural - Front Not Published 9.5x16 R1 Agricultural - Rear Not Published 13.6x28; 16.9x24 R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front Not Published 10-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System FLx2813: skid steer quick attach; FLx2815: pin-type or skid steer L135E: optional skid steer tool carrier Loader Model FLx2813; FLx2815 L135E Loader Lift Height 111 in (FLx2813 and FLx2815 loaders) L135E: 110.2 in Loader Lift Capacity (Full Height) FLx2813: 3,016 lb; FLx2815: 2,810 lb L135E: 2,430 lb Loader Breakout Force FLx2813: 4,176 lb; FLx2815: 4,240 lb L135E: 2,870 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
