▶ EngineEngine Manufacturer Iseki FPT Engine Model Iseki E4FH Not Published Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, FPT turbocharged & aftercooled No. of Cylinders 4 3 Displacement 148.6 in³ 135.9 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 53.6 hp 53 hp PTO Power 40 hp 45 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dry Dry Fuel System Common rail direct injection Electronic high pressure common rail Alternator Not Published 75 A ▶ HydraulicsPump Type Two gear-type pumps for steering and 3-point/remotes Engine-driven dual gear-type Implement Flow 12.6 gpm 11.9 gpm Steering Flow 7 gpm 5.5 gpm Total Hydraulic Flow 19.6 gpm (12.6 + 7, computed) 17.4 gpm (11.9 + 5.5, computed) Overall Hydraulic Pump Flow 19.6 gpm (12.6 + 7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 2 ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 17.2 gal Coolant Capacity 7.61 qt Not Published Crankcase Capacity 7.82 qt Not Published Transmission / Hydraulic System Capacity 10.04 gal Not Published Front Axle Fluid Capacity 9 qt Not Published ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent PTO Rear 540 rpm (1-3/8 in) 540 / 540E Mid-PTO Availability Optional, 2,000 rpm Not Published Category, 3-Point Hitch Category I and II Category 1/2 Hitch Lift Capacity 3,483 lb Not Published Hitch Lift Capacity (at 24”) 3,086 lb 2,701 lb Lift Control Type Not Published Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle 8x8 mechanical shuttle (dry clutch) No. of Speeds 12 forward and 12 reverse 8 forward / 8 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Dry clutch Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; deluxe cab: air-ride seat with armrests Not Published Front Axle Type Solid cast front axle 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.3 in MFD: 134.0 in; 2WD: 129.5 in Overall Width 70.1 in 67.5 in Wheelbase Not Published MFD: 77.7 in; 2WD: 77.5 in Ground Clearance 14.0 in Not Published Min. Turn Radius without Brakes Not Published MFD: 190.9 in; 2WD: 135.8 in Height to Top of ROPS 102.4 in MFD: 97.4 in; 2WD: 92.7 in Height to Top of ROPS (folded) Not Published 75.9 in Height to Top of Cab Model 92.9 in Not Published ▶ WeightTractor Weight (Base) ROPS: 4,035 lb; Cab: 4,420 lb MFD: 5,060 lb; 2WD: 4,442 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 agricultural (bar tread) or R4 industrial tread R1 Agricultural - Front 9.5-16 MFD: 8.3x24; 2WD: 7.5x16 R1 Agricultural - Rear 13.6-28 standard; 16.9-24 optional MFD: 13.6x28; 2WD: 13.6x28 R3 Turf - Front 27x10.50-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 10-16.5 MFD: 12.5x18 R4 Industrial - Rear 14.9-24; 17.5L-24 MFD: 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System FL2814: pin-type or skid steer Compatible loaders: L545, L555 Loader Model FL2814 L545; L555 Loader Lift Height FL2814: 111 in L545: 106 in; L555: 105 in Loader Lift Capacity (Full Height) FL2814: 2,570 lb L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb Loader Breakout Force FL2814: 3,910 lb L545: 3,131 lb; L555: 3,527 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
