▶ EngineEngine Manufacturer Iseki FPT Engine Model Iseki E4FH Not Published Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final No. of Cylinders 4 3 Displacement 148.6 in³ 178.8 in³ Rated Engine Speed 2600 rpm 2300 rpm Engine Power (Gross) 53.6 hp 54 hp PTO Power 40 hp 40 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System Common rail direct injection Electronic high pressure common rail Alternator Not Published 120 A ▶ HydraulicsPump Type Two gear-type pumps for steering and 3-point/remotes Fixed displacement Implement Flow 12.6 gpm 12.6 gpm Steering Flow 7 gpm Not Published Total Hydraulic Flow 19.6 gpm (12.6 + 7, computed) Not Published Overall Hydraulic Pump Flow 19.6 gpm (12.6 + 7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 21.7 gal Coolant Capacity 7.61 qt Not Published Crankcase Capacity 7.82 qt Not Published Transmission / Hydraulic System Capacity 10.04 gal Not Published Front Axle Fluid Capacity 9 qt Not Published ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent PTO Rear 540 rpm (1-3/8 in) 540 (standard); 540/540E (optional) Mid-PTO Availability Optional, 2,000 rpm Not Published Category, 3-Point Hitch Category I and II Category 1/2 Hitch Lift Capacity 3,483 lb 5,952 lb (optional hitch 6,614 lb) Hitch Lift Capacity (at 24”) 3,086 lb 4,300 lb (optional hitch 4,740 lb) Lift Control Type Not Published Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 power shuttle (wet clutch); optional 12x12 mechanical shuttle (dry clutch) or 12x12 with creeper (20x20) No. of Speeds 12 forward and 12 reverse MFD: 12F/12R; 2WD: 8F/8R; optional 12F/12R mechanical or 20F/20R creeper Max Travel Speed (Forward) Not Published 18.6 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published MFD: wet clutch (12x12 power shuttle); 2WD: wet clutch (8x8 power shuttle); optional dry clutch (12x12 mechanical shuttle) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Wet disc Wet disc Seat Suspension & Adjustability Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; deluxe cab: air-ride seat with armrests Mechanical contoured seat, adjustable; optional air-ride seat Front Axle Type Solid cast front axle 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.3 in 155.3 in Overall Width 70.1 in Not Published Wheelbase Not Published 2WD: 82.1 in; MFD: 83.6 in Ground Clearance 14.0 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.4 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in 2WD: 98 in; MFD: 100 in ▶ WeightTractor Weight (Base) ROPS: 4,035 lb; Cab: 4,420 lb 2WD Cab: 6,173 lb; 2WD Non-cab: 5,622 lb; MFD Cab: 6,834 lb; MFD Non-cab: 6,283 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial R1 Agricultural - Front 9.5-16 2WD: 9.5L-15; MFD: 11.2x24 R1 Agricultural - Rear 13.6-28 standard; 16.9-24 optional 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) R3 Turf - Front 27x10.50-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 14.9-24; 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System FL2814: pin-type or skid steer Not Published Loader Model FL2814 L610 Loader Lift Height FL2814: 111 in 130.3 in Loader Lift Capacity (Full Height) FL2814: 2,570 lb NSL: 1,828 lb; MSL: 3,153 lb Loader Breakout Force FL2814: 3,910 lb Not Published ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty Not Published
