▶ EngineEngine Manufacturer Iseki KIOTI (Daedong) Engine Model E4FH 4A220TLWB Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Water-cooled 4-cycle diesel No. of Cylinders 4 4 Displacement 148.6 in³ 134.1 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 53.6 hp 54 hp PTO Power 40 hp 45.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid cooled Not Published Air Cleaner Dry High efficiency air filter with cyclone pre-cleaner canister Fuel System Common rail direct injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Two gear-type pumps for steering and 3-point/remotes Tandem gear Implement Flow 12.6 gpm 9.88 gpm Steering Flow 7 gpm 4.33 gpm Total Hydraulic Flow 19.6 gpm (12.6 + 7, computed) 14.2 gpm Overall Hydraulic Pump Flow 19.6 gpm (12.6 + 7, computed) 14.2 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 18.0 gal Coolant Capacity 7.61 qt Not Published Crankcase Capacity 7.82 qt Not Published Transmission / Hydraulic System Capacity 10.04 gal Not Published Front Axle Fluid Capacity 9 qt Not Published ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Hydraulic independent PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability Optional, 2000 rpm Not Published Category, 3-Point Hitch Category I and II Category II (Category I ends optional) Hitch Lift Capacity 3,483 lb Not Published Hitch Lift Capacity (at 24”) 3,086 lb 2,654 lb Lift Control Type Not Published Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle Synchronized shuttle No. of Speeds 12 forward and 12 reverse 12F/12R Max Travel Speed (Forward) Not Published 16.42 mph Max Travel Speed (Reverse) Not Published 13.59 mph Clutch Not Published Dry single Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; upgraded cab: air-suspension seat with armrests Adjustable seat Front Axle Type Solid cast front axle 4WD (bevel gear front wheel drive, push-button engagement) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 70.1 in 69.3 in (minimum tread) Wheelbase Not Published 75.6 in Ground Clearance 14.0 in 17.5 in Min. Turn Radius without Brakes Not Published 145 in Height to Top of ROPS 102.4 in 106.5 in Height to Top of ROPS (folded) Not Published 85.5 in Height to Top of Cab Model 92.9 in 99.6 in Overall Length 132.3 in 130.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) ROPS: 4,035 lb; Cab: 4,420 lb 4,795 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-20 R1 Agricultural - Rear 13.6-28 standard; 16.9-24 optional 14.9-28 R3 Turf - Front 27x10.50-15 29x12.5-15 R3 Turf - Rear 44x18.00-20 44x18-20 R4 Industrial - Front 10-16.5 14x17.5 R4 Industrial - Rear 14.9-24; 17.5L-24 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System FL2814: skid steer quick attach KL551: universal quick-attach bucket mount, 78 in QA bucket Loader Model FL2814 KL551; KL1595 Loader Lift Height FL2814: 111 in (at pivot pin) KL551: 113.58 in; KL1595: 127.52 in Loader Lift Capacity (Full Height) FL2814: 2,570 lb (at pivot pin) KL551: 2,850 lb; KL1595: 2,685 lb Loader Breakout Force FL2814: 3,910 lb (at pivot pin) KL551: 4,675 lb; KL1595: 4,500 lb ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
