▶ EngineEngine Manufacturer Iseki Simpson Engine Model Iseki E4FH SJV326 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, turbocharged, intercooled, liquid-cooled diesel No. of Cylinders 4 3 Displacement 148.6 in³ 157.9 in³ Rated Engine Speed 2600 rpm 2000 rpm Engine Power (Gross) 53.6 hp 55 hp PTO Power 40 hp 46 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid cooled Air Cleaner Dry Not Published Fuel System Common rail direct injection Electronically controlled high-pressure common rail Alternator Not Published Not Published ▶ HydraulicsPump Type Two gear-type pumps for steering and 3-point/remotes Mark 1A scotch yoke piston pump Implement Flow 12.6 gpm Not Published Steering Flow 7 gpm Not Published Total Hydraulic Flow 19.6 gpm (12.6 + 7, computed) 15.7 gpm Overall Hydraulic Pump Flow 19.6 gpm (12.6 + 7, computed) 15.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 10.6 gpm No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 14.5 gal Coolant Capacity 7.61 qt 4 gal Crankcase Capacity 7.82 qt 2.5 gal Transmission / Hydraulic System Capacity 10.04 gal 10.5 gal Front Axle Fluid Capacity 9 qt 4WD: 1.5 gal differential, plus 0.23 gal per wheel end ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation 2WD: Live; 4WD: Independent PTO Rear 540 rpm (1-3/8 in) 540 rpm, 6-spline Mid-PTO Availability Optional, 2,000 rpm Not Published Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity 3,483 lb 4,519 lb Hitch Lift Capacity (at 24”) 3,086 lb 2,755 lb Lift Control Type Not Published Draft, position and response control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle 2WD: 8F x 2R SideShift sliding gear; 4WD: 8F x 8R synchro shuttle No. of Speeds 12 forward and 12 reverse 2WD: 8 forward and 2 reverse; 4WD: 8 forward and 8 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published 2WD: dual stage dry; 4WD: split torque Differential Lock & Limited Slip Options Not Published Mechanical engagement via right-side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering with separate reservoir Brakes Wet disc Oil-immersed wet disc Seat Suspension & Adjustability Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; deluxe cab: air-ride seat with armrests ReverseRise adjustable seat with fixed steering column Front Axle Type Solid cast front axle 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.3 in 2WD: 138 in; 4WD: 139 in Overall Width 70.1 in 66.5 in Wheelbase Not Published 2WD: 80.7 in; 4WD: 81.5 in Ground Clearance 14.0 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.4 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in Not Published ▶ WeightTractor Weight (Base) ROPS: 4,035 lb; Cab: 4,420 lb 2WD: 4,894 lb; 4WD: 5,394 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial 2WD standard (ag): 6.00x16 front, 13.6x28 rear; 2WD optional (ag): 7.5x16 front, 16.6x28 rear; 4WD standard (ag): 9.5x24 front, 14.9x28 rear; 4WD industrial: 10.5/80-18 front with 14.9x24 rear, or 12.5/80-18 front with 16.9x24 rear R1 Agricultural - Front 9.5-16 2WD: 6.00x16 (7.5x16 optional); 4WD: 9.5x24 R1 Agricultural - Rear 13.6-28 standard; 16.9-24 optional 2WD: 13.6x28 (16.6x28 optional); 4WD: 14.9x28 R3 Turf - Front 27x10.50-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 10-16.5 4WD: 10.5/80-18 or 12.5/80-18 R4 Industrial - Rear 14.9-24; 17.5L-24 4WD: 14.9x24 or 16.9x24 ▶ Loader & AttachmentsQuick Attach Loader System FL2814: pin-type or skid steer Skid steer style coupling Loader Model FL2814 FLx2815 (2WD); 911X (4WD) Loader Lift Height FL2814: 111 in FLx2815: 111 in; 911X: 114 in Loader Lift Capacity (Full Height) FL2814: 2,570 lb FLx2815: 2,810 lb; 911X: 2,470 lb Loader Breakout Force FL2814: 3,910 lb FLx2815: 4,240 lb; 911X: 2,755 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
