▶ EngineEngine Manufacturer Iseki Shibaura Engine Model Iseki E4FH N4LDI-TA Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 4 4 Displacement 148.6 in³ 135.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 53.6 hp 57.3 hp PTO Power 40 hp Gear: 48.7 hp; HST: 45.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dry Primary and secondary elements Fuel System Common rail direct injection Electronically controlled high-pressure common rail Alternator Not Published 90 A ▶ HydraulicsPump Type Two gear-type pumps for steering and 3-point/remotes Gear-type single pump Implement Flow 12.6 gpm Not Published Steering Flow 7 gpm Not Published Total Hydraulic Flow 19.6 gpm (12.6 + 7, computed) 12.4 gpm Overall Hydraulic Pump Flow 19.6 gpm (12.6 + 7, computed) 12.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Not Published 1 factory-installed; up to 3 field-installed ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 14 gal Coolant Capacity 7.61 qt 1.66 gal Crankcase Capacity 7.82 qt 1.53 gal Transmission / Hydraulic System Capacity 10.04 gal 10.04 gal Front Axle Fluid Capacity 9 qt 2.21 gal ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent, electro-hydraulically engaged PTO Rear 540 rpm (1-3/8 in) 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability Optional, 2,000 rpm No mid-PTO Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity 3,483 lb Not Published Hitch Lift Capacity (at 24”) 3,086 lb 2,425 lb Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle Gear: 8 x 8 (4-speed x 2 sub-range) Syncro-Shuttle; HST: 3-range mechanical HST No. of Speeds 12 forward and 12 reverse Gear: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Dry single-disc Differential Lock & Limited Slip Options Not Published Mechanical engagement (Gear: right side heel pedal; HST: left side heel pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Internal wet disc, 2 pedals (Gear: right hand; HST: left hand) Seat Suspension & Adjustability Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; deluxe cab: air-ride seat with armrests Suspended vinyl seat with retractable seatbelt Front Axle Type Solid cast front axle Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.3 in 133 in Overall Width 70.1 in 74 in Wheelbase Not Published 78 in Ground Clearance 14.0 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.4 in 104 in Height to Top of ROPS (folded) Not Published 80 in Height to Top of Cab Model 92.9 in Not Published ▶ WeightTractor Weight (Base) ROPS: 4,035 lb; Cab: 4,420 lb Gear: 3,847 lb; HST: 3,891 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 ag: 9.5x16 front, 13.6x28 or 16.9x24 rear; R3 turf: 27x10.50-15 front, 44x18.00-20 rear; R4 industrial: 10-16.5 front, 17.5L-24 rear R1 Agricultural - Front 9.5-16 9.5x16 R1 Agricultural - Rear 13.6-28 standard; 16.9-24 optional 13.6x28; 16.9x24 R3 Turf - Front 27x10.50-15 27x10.50-15 R3 Turf - Rear 44x18.00-20 44x18.00-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 14.9-24; 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System FL2814: pin-type or skid steer L135E: optional skid steer tool carrier Loader Model FL2814 L135E Loader Lift Height FL2814: 111 in L135E: 110.2 in Loader Lift Capacity (Full Height) FL2814: 2,570 lb L135E: 2,430 lb Loader Breakout Force FL2814: 3,910 lb L135E: 2,870 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 5-year powertrain warranty
