▶ EngineEngine Manufacturer Iseki LS Mtron Engine Model Not Published L3C19-T Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 3 Cylinder, Liquid-cooled, Diesel, TC, CRDI No. of Cylinders 4 3 Displacement 148.6 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 57.3 hp 57 hp PTO Power Mech: 48 hp; HST: 45.3 hp 48.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Not Published Common rail direct injection (CRDI) Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Two gear-type pumps for steering and 3-point/remotes Not Published Implement Flow 12.6 gpm 8.2 gpm Steering Flow 7.0 gpm 4.1 gpm Total Hydraulic Flow 19.6 gpm (12.6 + 7.0, computed) 12.3 gpm Overall Hydraulic Pump Flow 19.6 gpm (12.6 + 7.0, computed) 12.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 3 Pair (2 Detent, 1 STD) No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 14 gal 10.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published 6.2 qt Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent PTO Rear 540 rpm (1-3/8 in) 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I and II Category II Hitch Lift Capacity 2,645 lb 2,755 lb Hitch Lift Capacity (at 24”) 2,425 lb 2,469 lb Lift Control Type Not Published Position & Draft ▶ Transmission & DrivetrainTransmission Type 8x8 synchro shuttle or 3-range hydrostatic Synchro shuttle No. of Speeds Mech: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) F16 x R16 Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Power Steering Brakes Wet disc Wet, Multi-disc Seat Suspension & Adjustability Spring-cushioned seat Not Published Front Axle Type Solid cast front axle Mechanical front-wheel drive (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.8 in 133 in Overall Width 70.1 in 62.5 in Wheelbase Not Published 73.2 in Ground Clearance 15 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103.8 in 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,869 lb 3,869 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 9.5-16 R1 Agricultural - Rear Not Published 13.6-24 R3 Turf - Front Not Published 28x8.5-15 R3 Turf - Rear Not Published 41x14-20 R4 Industrial - Front Not Published 12-16.5 R4 Industrial - Rear Not Published 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System FLx2813: skid steer quick attach; FLx2815: pin-type or skid steer LL4106, LL4001: 2 lever skid steer coupler (universal skid steer attachments) Loader Model FLx2813; FLx2815 LL4106; LL4001 Loader Lift Height 111 in (FLx2813 and FLx2815 loaders) LL4106: 94.4 in; LL4001: 104.3 in Loader Lift Capacity (Full Height) FLx2813: 3,016 lb; FLx2815: 2,810 lb LL4106: 2,680 lb; LL4001: 2,998 lb Loader Breakout Force FLx2813: 4,176 lb; FLx2815: 4,240 lb LL4106: 4,063 lb; LL4001: 4,295 lb ▶ WarrantyWarranty Length & Coverage 5-year powertrain warranty 6-year limited powertrain warranty
