▶ EngineEngine Manufacturer Iseki Simpson Engine Model Not Published SJV326 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, turbocharged, intercooled No. of Cylinders 4 3 Displacement 148.6 in³ 157.9 in³ Rated Engine Speed 2600 rpm 2000 rpm Engine Power (Gross) 57.3 hp 55 hp PTO Power Mech: 48 hp; HST: 45.3 hp 45.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Not Published Electronically controlled high-pressure common rail Alternator Not Published Not Published ▶ HydraulicsPump Type Two gear-type pumps for steering and 3-point/remotes Mark 1A scotch yoke piston pump Implement Flow 12.6 gpm Not Published Steering Flow 7.0 gpm Not Published Total Hydraulic Flow 19.6 gpm (12.6 + 7.0, computed) 15.7 gpm Overall Hydraulic Pump Flow 19.6 gpm (12.6 + 7.0, computed) 15.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 10.6 gpm No. of Standard Remote Valves Not Published One No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 14 gal 14.5 gal Coolant Capacity Not Published 4 gal Crankcase Capacity Not Published 2.5 gal Transmission / Hydraulic System Capacity Not Published 10.5 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Live PTO Rear 540 rpm (1-3/8 in) 540 rpm, 6-spline Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I and II Category I and II Hitch Lift Capacity 2,645 lb 4,519 lb Hitch Lift Capacity (at 24”) 2,425 lb 2,755 lb Lift Control Type Not Published Draft, position and response control ▶ Transmission & DrivetrainTransmission Type 8x8 synchro shuttle or 3-range hydrostatic 8F x 2R SideShift sliding gear No. of Speeds Mech: 8 forward and 8 reverse; HST: infinite forward and reverse (3-range) 8 forward and 2 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Mechanical engagement via right-side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic steering with separate reservoir Brakes Wet disc Oil-immersed wet disc Seat Suspension & Adjustability Spring-cushioned seat ReverseRise adjustable seat with fixed steering column Front Axle Type Solid cast front axle Straight adjustable (2WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 70.1 in 66.5 in Wheelbase Not Published 80.7 in Ground Clearance 15 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103.8 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 132.8 in 138 in ▶ WeightTractor Weight (Base) 3,869 lb 4,894 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Standard (ag): 6.00x16 front, 13.6x28 rear; optional (ag): 7.5x16 front, 16.6x28 rear R1 Agricultural - Front Not Published 6.00x16 (7.5x16 optional) R1 Agricultural - Rear Not Published 13.6x28 (16.6x28 optional) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System FLx2813: skid steer quick attach Skid steer style coupling Loader Model FLx2813 FLx2815 Loader Lift Height FLx2813: 111 in (at pivot pin) FLx2815: 111 in; 911X: 114 in Loader Lift Capacity (Full Height) FLx2813: 3,016 lb (at pivot pin) FLx2815: 2,810 lb (at pivot pin); 911X: 2,470 lb (at pivot pins) Loader Breakout Force FLx2813: 4,176 lb (at pivot pin) FLx2815: 4,240 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty 5-year powertrain warranty
