▶ EngineEngine Manufacturer Iseki John Deere Engine Model Not Published Not Published Engine Type 4-cylinder, turbocharged, liquid-cooled diesel Diesel, turbocharged No. of Cylinders 4 3 Displacement 148.6 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 60.3 hp 60 hp PTO Power Mech: 47 hp; HST: 44.6 hp OOS: 45.6 hp; Cab: 42.9 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System Common rail direct injection with electronic engine management Electronically controlled, high-pressure common rail Alternator Not Published OOS: 70 A; Cab: 110 A ▶ HydraulicsPump Type Two gear-type pumps Tandem gear pump (implement + steering) Implement Flow Mech: 12.7 gpm; HST: 12.6 gpm 11.4 gpm Steering Flow 7.1 gpm 6.8 gpm Total Hydraulic Flow Mech: 19.8 gpm (12.7 + 7.1, computed); HST: 19.7 gpm (12.6 + 7.1, computed) 18.2 gpm Overall Hydraulic Pump Flow Mech: 19.8 gpm (12.7 + 7.1, computed); HST: 19.7 gpm (12.6 + 7.1, computed) 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published 11.4 gpm at a single rear SCV No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 14.0 gal OOS: 19.6 gal; Cab: 21.6 gal Coolant Capacity 7.61 qt Open operator station: 2.85 gal; Cab: 3.08 gal Crankcase Capacity 7.82 qt 9.0 qt (with filter) Transmission / Hydraulic System Capacity Mech: 11.35 gal; HST: 9.25 gal 8.36 gal (9x3); 9.46 gal (12x12) Front Axle Fluid Capacity 9 qt DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent PTO Rear 540 rpm, 1.375 in 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I & II Category 2, convertible to 1 Hitch Lift Capacity Mech: 3,747 lb; HST: 3,483 lb 3,968 lb Hitch Lift Capacity (at 24”) Mech: 3,307 lb; HST: 3,086 lb 3,192 lb Lift Control Type Not Published Position control, draft control, adjustable rate of drop ▶ Transmission & DrivetrainTransmission Type Mech: 12x12 power shuttle; HST: 3-range Servo-HST SyncShuttle (standard); PowrReverser (optional) No. of Speeds Mech: 12 forward and 12 reverse; HST: infinite forward and reverse (3-range) 9F/3R (SyncShuttle); 12F/12R (PowrReverser) Max Travel Speed (Forward) Not Published 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) Max Travel Speed (Reverse) Not Published 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) Clutch Not Published Wet traction clutch (PowrReverser) Differential Lock & Limited Slip Options Not Published Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Not Published Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Not Published Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment Front Axle Type Four-wheel drive 2WD or MFWD Front Axle Rating Not Published Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) Drawbar Capacity Not Published 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Mech: 136.2 in; HST: 132.3 in 143.3 in Overall Width 71.3 in Not Published Wheelbase Not Published 80.7 in Ground Clearance Mech: 11.6 in; HST: 14.0 in Not Published Min. Turn Radius without Brakes Not Published 137.8 in (2WD); 183.1 in (4WD); 153.5 in (4WD, Carraro axle) Height to Top of ROPS 103.1 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.3 in Not Published ▶ WeightTractor Weight (Base) ROPS: 4,288 lb; Cab: 4,674 lb 5,445 to 6,702 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Ag / R3 Turf / R4 Industrial / Snow R1 Agricultural - Front Not Published 11L-15 R1 Agricultural - Rear Not Published 14.9-28 R3 Turf - Front Not Published 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) R3 Turf - Rear Not Published 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) R4 Industrial - Front Not Published 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 R4 Industrial - Rear Not Published 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer 512 or 520M Loader Model FL2814 512 or 520M Loader Lift Height FL2814: 111 in 512: 113 in; 520M: 132 in Loader Lift Capacity (Full Height) FL2814: 2,570 lb 512: 2,453 lb; 520M: 3,523 lb Loader Breakout Force FL2814: 3,910 lb 512: 4,781 lb; 520M: 4,641 lb ▶ WarrantyWarranty Length & Coverage Not Published 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
