▶ EngineEngine Manufacturer Iseki Shibaura Engine Model E4FH N4LDI-TA Engine Type 4-cylinder, turbocharged diesel 4-cylinder turbocharged intercooled diesel, liquid-cooled No. of Cylinders 4 4 Displacement 148.3 in³ 135.2 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 60.3 hp 59.9 hp PTO Power Mech: 47 hp; HST: 44.6 hp Mech: 46.1 hp; HST: 44.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Common-rail, direct injection, electronic engine management Common rail direct injection Alternator Not Published Not Published ▶ HydraulicsPump Type Two gear-type pumps Engine-driven gear-type pump Implement Flow Mech: 12.7 gpm; HST: 12.6 gpm Not Published Steering Flow 7.1 gpm Not Published Total Hydraulic Flow Mech: 19.8 gpm (12.7 + 7.1, computed); HST: 19.7 gpm (12.6 + 7.1, computed) Not Published Overall Hydraulic Pump Flow Mech: 19.8 gpm (12.7 + 7.1, computed); HST: 19.7 gpm (12.6 + 7.1, computed) 12x12 Power Shuttle: 12.7 gpm; HST: 12.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 12.1 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 14 gal Coolant Capacity 7.61 qt 7.08 qt Crankcase Capacity 7.82 qt 6.87 qt Transmission / Hydraulic System Capacity Mech: 11.35 gal; HST: 9.25 gal Power Shuttle: 11.35 gal; HST: 9.25 gal Front Axle Fluid Capacity 9 qt 9 qt ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent, with soft-start feature PTO Rear 540 rpm 540 rpm (6-spline) Mid-PTO Availability Not Published Optional, 2,000 rpm (not offered with the 12x12 power shuttle) Category, 3-Point Hitch Category I & II Category I with extendable ball ends Hitch Lift Capacity Mech: 3,747 lb; HST: 3,483 lb Not Published Hitch Lift Capacity (at 24”) Mech: 3,307 lb; HST: 3,086 lb 12x12 Power Shuttle: 3,307 lb; HST: 3,086 lb Lift Control Type Not Published Draft control optional ▶ Transmission & DrivetrainTransmission Type Mech: 12x12 power shuttle; HST: 3-range Servo-HST 12 x 12 power shuttle or 3-range hydrostatic No. of Speeds Mech: 12 forward and 12 reverse; HST: infinite forward and reverse (3-range) 12 x 12 Power Shuttle (3 ranges, 4 gears); HST: 3-range, infinite speeds in each range Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Multiple stage wet type Differential Lock & Limited Slip Options Not Published Mechanical engagement via right side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Not Published Internal wet disc brakes, independent foot pedals Seat Suspension & Adjustability Not Published Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering Front Axle Type Four-wheel drive Cast-steel 4WD front axle, center driveline, bevel-gear final drives Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 71.3 in 12x12 Power Shuttle: 71.1 in; HST: 65.4 in Wheelbase Not Published 12x12 Power Shuttle: 80.3 in; HST: 77.9 in Ground Clearance Mech: 11.6 in; HST: 14.0 in 14.8 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103.1 in 12x12 Power Shuttle: 103.2 in; HST: 102.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.3 in 12x12 Power Shuttle: 93.3 in; HST: 92.9 in Overall Length Mech: 136.2 in; HST: 132.3 in HST: 132.3 in ▶ WeightTractor Weight (Base) ROPS: 4,288 lb; Cab: 4,674 lb 12x12 Power Shuttle: 4,233 lb (ROPS base weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published AG, Turf, Industrial, Snow R1 Agricultural - Front Not Published 9.5x16 R1 Agricultural - Rear Not Published 16.9x26 R3 Turf - Front Not Published 27x10.50-15 R3 Turf - Rear Not Published 44x18.00-20 R4 Industrial - Front Not Published 12-16.5 R4 Industrial - Rear Not Published 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid steer DL135: Skid steer quick attach Loader Model FL2814 DL135 Loader Lift Height FL2814: 111 in (at pivot pin) DL135: 111 in (at pivot pin) Loader Lift Capacity (Full Height) FL2814: 2,570 lb (at pivot pin) DL135: 2,610 lb (at pivot pin, full height) Loader Breakout Force FL2814: 3,910 lb (at pivot pin) DL135: 4,000 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Five-year powertrain warranty
