▶ EngineEngine Manufacturer Iseki Simpson Engine Model Not Published SJV326 Engine Type 4-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, turbocharged, intercooled, liquid-cooled diesel No. of Cylinders 4 3 Displacement 148.6 in³ 157.9 in³ Rated Engine Speed 2600 rpm 2000 rpm Engine Power (Gross) 60.3 hp 65 hp PTO Power Mech: 47 hp; HST: 44.6 hp 55 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Common rail direct injection with electronic engine management Electronically controlled high-pressure common rail Alternator Not Published Not Published ▶ HydraulicsPump Type Two gear-type pumps Mark 1A scotch yoke piston pump Implement Flow Mech: 12.7 gpm; HST: 12.6 gpm Not Published Steering Flow 7.1 gpm Not Published Total Hydraulic Flow Mech: 19.8 gpm (12.7 + 7.1, computed); HST: 19.7 gpm (12.6 + 7.1, computed) 15.7 gpm Overall Hydraulic Pump Flow Mech: 19.8 gpm (12.7 + 7.1, computed); HST: 19.7 gpm (12.6 + 7.1, computed) 15.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 10.6 gpm No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 14.0 gal 14.5 gal Coolant Capacity 7.61 qt 4 gal Crankcase Capacity 7.82 qt 2.5 gal Transmission / Hydraulic System Capacity Mech: 11.35 gal; HST: 9.25 gal 10.5 gal Front Axle Fluid Capacity 9 qt 4WD: 1.5 gal differential, plus 0.23 gal per wheel end ▶ PTO & HitchPTO Type Independent with SoftStart electronic modulation Independent PTO Rear 540 rpm, 1.375 in 540 rpm, 6-spline Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I & II Category I and II Hitch Lift Capacity Mech: 3,747 lb; HST: 3,483 lb 4,519 lb Hitch Lift Capacity (at 24”) Mech: 3,307 lb; HST: 3,086 lb 2,755 lb Lift Control Type Not Published Draft, position and response control ▶ Transmission & DrivetrainTransmission Type Mech: 12x12 power shuttle; HST: 3-range Servo-HST 8F x 8R synchro shuttle No. of Speeds Mech: 12 forward and 12 reverse; HST: infinite forward and reverse (3-range) 8 forward and 8 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Split torque clutch Differential Lock & Limited Slip Options Not Published Mechanical engagement via right-side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering with separate reservoir Brakes Not Published Oil-immersed wet disc Seat Suspension & Adjustability Not Published ReverseRise adjustable seat with fixed steering column Front Axle Type Four-wheel drive 2WD: straight, telescopically adjustable; 4WD: heavy-duty planetary reduction Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Mech: 136.2 in; HST: 132.3 in 2WD: 138 in; 4WD: 139 in Overall Width 71.3 in 69.9 in Wheelbase Not Published 2WD: 80.7 in; 4WD: 81.5 in Ground Clearance Mech: 11.6 in; HST: 14.0 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103.1 in 93.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 93.3 in Not Published ▶ WeightTractor Weight (Base) ROPS: 4,288 lb; Cab: 4,674 lb 2WD: 5,115 lb; 4WD: 5,710 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 2WD standard (ag): 7.5x16 front, 14.9x28 rear; 4WD standard (ag): 9.5x24 front, 14.9x28 rear; industrial: 11L15 front (2WD) or 10.8/80-18 front (4WD) with 14.9x24 rear, or 12.5/80-18 front with 16.9x24 rear (4WD) R1 Agricultural - Front Not Published 2WD: 7.5x16; 4WD: 9.5x24 R1 Agricultural - Rear Not Published 14.9x28 (2WD and 4WD) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 2WD: 11L15; 4WD: 10.8/80-18 or 12.5/80-18 R4 Industrial - Rear Not Published 14.9x24 or 16.9x24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Skid steer Skid steer style coupling Loader Model FL2814 FLx2815 (2WD); 911X (4WD) Loader Lift Height FL2814: 111 in FLx2815: 111 in; 911X: 114 in Loader Lift Capacity (Full Height) FL2814: 2,570 lb FLx2815: 2,810 lb; 911X: 2,470 lb Loader Breakout Force FL2814: 3,910 lb FLx2815: 4,240 lb; 911X: 2,755 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year powertrain warranty
