▶ EngineEngine Manufacturer AGCO Power Iseki Engine Model 33 AWIC Not Published Engine Type 3-cylinder, intercooled turbocharged diesel 4-cylinder, turbocharged diesel No. of Cylinders 3 4 Displacement 201 in³ Not Published Rated Engine Speed 2200 rpm 2600 rpm Engine Power (Gross) 75 hp 65.7 hp PTO Power 60 hp 50 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid cooled Not Published Air Cleaner Dual element (primary and secondary) Not Published Fuel System High-pressure common rail direct fuel injection Not Published Alternator 80 A Not Published ▶ HydraulicsPump Type Two-stage pump Two gear-type pumps Implement Flow Not Published 12.6 gpm Steering Flow Not Published 7.1 gpm Total Hydraulic Flow Not Published 19.7 gpm (12.6 + 7.1, computed) Overall Hydraulic Pump Flow Not Published 19.7 gpm (12.6 + 7.1, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 17.2 gpm Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 33 gal 14.0 gal Coolant Capacity 4.2 gal Not Published Crankcase Capacity 3.3 gal Not Published Transmission / Hydraulic System Capacity Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Not Published Front Axle Fluid Capacity Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive Not Published ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Independent with SoftStart electronic modulation PTO Rear 540/540E standard; 540/1000 optional 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category I & II Hitch Lift Capacity Not Published 3,483 lb Hitch Lift Capacity (at 24”) 4,850 lb 3,483 lb Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift 3-range Servo-HST with 2 stages (Hi and Lo), electronically controlled No. of Speeds 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 Not Published Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Multidisc wet clutch with easy shift knob and electrohydraulic power shuttle lever Not Published Differential Lock & Limited Slip Options Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch; 4WD front axle Hydra-Lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Not Published Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Not Published Seat Suspension & Adjustability Cab: mechanical swiveling seat with armrests, air-ride swivel seat optional; Platform: mechanical spring suspension seat with armrests Not Published Front Axle Type Heavy-duty 2WD or 4WD front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 132.3 in Overall Width 60.3 in (minimum, with std. 420/85R30 rear tires) 70.1 in Wheelbase 88.5 in Not Published Ground Clearance Not Published 14.0 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 92.9 in ▶ WeightTractor Weight (Base) 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb 4,608 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 9.5L-15 front, 420/85R30 rear; 4WD: 320/85R24 front, 420/85R30 rear Not Published R1 Agricultural - Front 2WD: 9.5L-15; 4WD: 320/85R24 Not Published R1 Agricultural - Rear 420/85R30 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System 931X and 936X: universal skid steer type quick release Skid steer Loader Model FL.3522, FL.3615, 931X, 936X FL2814 Loader Lift Height FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) FL2814: 111 in Loader Lift Capacity (Full Height) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) FL2814: 2,570 lb Loader Breakout Force Not Published FL2814: 3,910 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
