▶ EngineEngine Manufacturer AGCO Power FPT Industrial Engine Model 33 AWIC S8000 Engine Type 3-cylinder, intercooled turbocharged diesel Turbocharged, intercooled 3-cylinder diesel No. of Cylinders 3 3 Displacement 201 in³ 179 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 75 hp 74 hp PTO Power 60 hp 60 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Not Published Air Cleaner Dual element (primary and secondary) Not Published Fuel System High-pressure common rail direct fuel injection Common rail fuel injection Alternator 80 A Not Published ▶ HydraulicsPump Type Two-stage pump Dual-pump Implement Flow Not Published 12.6 gpm Steering Flow Not Published 7.6 gpm Total Hydraulic Flow Not Published 20.2 gpm Overall Hydraulic Pump Flow Not Published 20.2 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow 17.2 gpm Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 1 3 ▶ Fluid CapacityFuel Tank Capacity 33 gal Not Published Coolant Capacity 4.2 gal Not Published Crankcase Capacity 3.3 gal Not Published Transmission / Hydraulic System Capacity Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Not Published Front Axle Fluid Capacity Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive Not Published ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Not Published PTO Rear 540/540E standard; 540/1000 optional 540/540E Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Not Published Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,850 lb 4,000 lb Lift Control Type Not Published Lift-O-Matic ▶ Transmission & DrivetrainTransmission Type 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift 12x12 Mechanical Shuttle No. of Speeds 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 12F/12R Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Multidisc wet clutch with easy shift knob and electrohydraulic power shuttle lever Not Published Differential Lock & Limited Slip Options Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch; 4WD front axle Hydra-Lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Straddle-deck platform Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Not Published Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Not Published Seat Suspension & Adjustability Cab: mechanical swiveling seat with armrests, air-ride swivel seat optional; Platform: mechanical spring suspension seat with armrests Vinyl suspension seat Front Axle Type Heavy-duty 2WD or 4WD front axle 4WD front axle, electronic engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 143 in Overall Width 60.3 in (minimum, with std. 420/85R30 rear tires) 57 in Wheelbase 88.5 in 73 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 97 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb 5,000 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 9.5L-15 front, 420/85R30 rear; 4WD: 320/85R24 front, 420/85R30 rear Not Published R1 Agricultural - Front 2WD: 9.5L-15; 4WD: 320/85R24 Not Published R1 Agricultural - Rear 420/85R30 320/70R20 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System 931X and 936X: universal skid steer type quick release Not Published Loader Model FL.3522, FL.3615, 931X, 936X Not Published Loader Lift Height FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) Not Published Loader Lift Capacity (Full Height) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) Not Published Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
