▶ EngineEngine Manufacturer AGCO Power FPT Engine Model 33 AWIC F5D Engine Type 3-cylinder, intercooled turbocharged diesel Turbocharged and intercooled 4-cylinder diesel No. of Cylinders 3 4 Displacement 201.4 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 95 hp 98 hp PTO Power 77 hp 82 hp Engine Emissions Constraints Tier 4 Tier 4A Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dual element (primary and secondary) Dual dry element Fuel System High-pressure common rail direct fuel injection Electronic high-pressure common-rail fuel injection Alternator 80 A 120 A ▶ HydraulicsPump Type Two-stage pump Dual engine-driven pumps (open center) Implement Flow Not Published 12.5 gpm (16.9 gpm optional) Steering Flow Not Published 7.3 gpm Total Hydraulic Flow Not Published 19.8 gpm (12.5 + 7.3, computed) Overall Hydraulic Pump Flow Not Published 19.8 gpm (12.5 + 7.3, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 17.2 gpm Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 1 2 (3rd remote available through Parts Division) ▶ Fluid CapacityFuel Tank Capacity 33 gal 30.3 gal Coolant Capacity 4.2 gal Not Published Crankcase Capacity 3.3 gal Not Published Transmission / Hydraulic System Capacity Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Not Published Front Axle Fluid Capacity Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive Not Published ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Independent, mechanical engagement PTO Rear 540/540E standard; 540/1000 optional 540/1000 (base); 540 (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (ball ends convert to Category I) Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,850 lb 5,620 lb Lift Control Type Not Published Single-lever position control with draft-sensing top link ▶ Transmission & DrivetrainTransmission Type 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift Not Published No. of Speeds 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 12F/12R mechanical (20F/12R mechanical with creeper; 12F/12R power shuttle; 20F/20R optional) Max Travel Speed (Forward) 2WD: 18 mph; 4WD: 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch with easy shift knob and electrohydraulic power shuttle lever Not Published Differential Lock & Limited Slip Options Hydraulic, electronically controlled; rear axle engaged via electrohydraulic rocker switch; 4WD front axle: hydraulic differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Power steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Wet disc (mechanical on ROPS, hydraulic on cab) Seat Suspension & Adjustability Cab: mechanical swiveling seat with armrests, air-suspension swivel seat optional; Platform: mechanical spring-suspension seat with armrests Air suspension seat with 15-degree swivel (optional, cab) Front Axle Type Heavy-duty 2WD or 4WD front axle 2WD or MFD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 60.3 in (minimum, with std. 420/85R30 rear tires) 83 in Wheelbase 88.5 in 89 in (MFD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 103 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 100 in Overall Length Not Published 149 in (MFD cab, 16.9R-34 rear tires) ▶ WeightTractor Weight (Base) 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb 7,937 lb (MFD cab, 16.9R-34 rear tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 420/85R30 standard Not Published R1 Agricultural - Front 2WD: 9.5L-15; 4WD: 320/85R24 Not Published R1 Agricultural - Rear 420/85R30 16.9R-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System 931X and 936X: universal skid steer type quick release Skid steer-style quick attach (hydraulic coupler) Loader Model FL.3522, FL.3615, 931X, 936X L620; L630; L735 Loader Lift Height FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL); L735: 137 in Loader Lift Capacity (Full Height) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) L620: 3,461 lb (NSL) / 3,573 lb (MSL); L630: 3,849 lb (NSL) / 4,204 lb (MSL); L735: 4,034 lb (NSL) / 3,505 lb (MSL) (maximum height at pins) Loader Breakout Force Not Published L620: 5,530 lb (NSL) / 5,483 lb (MSL); L630: 6,649 lb (NSL) / 6,767 lb (MSL); L735: 4,960 lb (NSL) / 4,122 lb (MSL) (breakout at pins) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
