▶ EngineEngine Manufacturer AGCO Power Kubota Engine Model 33 AWIC V3800CR-TIEF4 Engine Type 3-cylinder, intercooled turbocharged diesel 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR No. of Cylinders 3 4 Displacement 201.4 in³ 230 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 95 hp 92.5 hp PTO Power 77 hp 76 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dual element (primary and secondary) Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System High-pressure common rail direct fuel injection Common rail direct injection Alternator 80 A 60 A ▶ HydraulicsPump Type Two-stage pump Gear pump Implement Flow Not Published 15.9 gpm Steering Flow Not Published 5.4 gpm Total Hydraulic Flow Not Published 21.3 gpm Overall Hydraulic Pump Flow Not Published 21.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 17.2 gpm 15.7 gpm No. of Standard Remote Valves 2 2 standard (3 maximum) No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 33 gal 27.7 gal Coolant Capacity 4.2 gal 11 qt Crankcase Capacity 3.3 gal 11.3 qt Transmission / Hydraulic System Capacity Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal 63.4 qt Front Axle Fluid Capacity Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540/540E standard; 540/1000 optional 540 rpm (540/540E on 12-speed models) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 7,055 lb Hitch Lift Capacity (at 24”) 4,850 lb 4,630 lb (8-speed); 6,063 lb (12-speed) Lift Control Type Not Published Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift Fully synchronized main gear shift with electro-hydraulic shuttle No. of Speeds 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 8 forward, 8 reverse (8-speed models); 12 forward, 12 reverse (12-speed models) Max Travel Speed (Forward) 2WD: 18 mph; 4WD: 25 mph 17.7 mph (8-speed); 22.6 mph (12-speed) Max Travel Speed (Reverse) Not Published 8-speed: 18.4 mph; 12-speed: 23.5 mph Clutch Wet clutch with easy shift knob and electrohydraulic power shuttle lever Multiple wet disc Differential Lock & Limited Slip Options Hydraulic, electronically controlled; rear axle engaged via electrohydraulic rocker switch; 4WD front axle: hydraulic differential lock Front: limited-slip differential; Rear: mechanical differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Hydrostatic power steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Hydraulic wet disc Seat Suspension & Adjustability Cab: mechanical swiveling seat with armrests, air-suspension swivel seat optional; Platform: mechanical spring-suspension seat with armrests Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type Heavy-duty 2WD or 4WD front axle Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,730 lb Drawbar Capacity Not Published 3,300 lb ▶ Dimensions & ManeuverabilityOverall Width 60.3 in (minimum, with std. 420/85R30 rear tires) 78.3 in Wheelbase 88.5 in 88.6 in Ground Clearance Not Published 17.7 in (minimum, drawbar bracket) Min. Turn Radius without Brakes Not Published 13.8 ft Height to Top of ROPS Not Published 98.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Applicable Overall Length Not Published 155.9 in ▶ WeightTractor Weight (Base) 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb 6,151 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 420/85R30 standard Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front 2WD: 9.5L-15; 4WD: 320/85R24 11.2-24 R1 Agricultural - Rear 420/85R30 18.4-30 R3 Turf - Front Not Published 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear Not Published 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front Not Published 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear Not Published 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System 931X and 936X: universal skid steer type quick release Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional Loader Model FL.3522, FL.3615, 931X, 936X LA1854 Loader Lift Height FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) 3,990 lb (height position); 4,144 lb (power position) Loader Breakout Force Not Published LA1854: 5,501 lb at bucket pivot pin (height position); 6,470 lb at bucket pivot pin (power position) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours
