▶ EngineEngine Manufacturer AGCO Power John Deere Engine Model 33 AWIC PowerTech PWL 4045 Engine Type 3-cylinder, intercooled turbocharged diesel Diesel, turbocharged, aftercooled No. of Cylinders 3 4 Displacement 201.4 in³ 276 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 100 hp 100 hp PTO Power 87 hp 85 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dual element (primary and secondary) Dry type with safety element Fuel System High-pressure common rail direct fuel injection High Pressure Common Rail Alternator 80 A OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Two-stage pump Tandem gear pump (implement + steering) Implement Flow Not Published 15.9 gpm Steering Flow Not Published 6.6 gpm Total Hydraulic Flow Not Published 22.5 gpm Overall Hydraulic Pump Flow Not Published 22.5 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 17.2 gpm Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 1 3 ▶ Fluid CapacityFuel Tank Capacity 33 gal OOS: 25 gal; Cab: 30 gal Coolant Capacity 4.2 gal Cab: 3 gal; OOS: 2.5 gal Crankcase Capacity 3.3 gal 3.2 gal (with filter) Transmission / Hydraulic System Capacity Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal 11.5 gal Front Axle Fluid Capacity Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive MFWD differential housing: 1.3 gal; MFWD wheel hub (each): 0.74 qt ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Independent, electrohydraulic engagement PTO Rear 540/540E standard; 540/1000 optional 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,850 lb 4,630 lb Lift Control Type Not Published Top link draft sensing; mechanical hitch controls ▶ Transmission & DrivetrainTransmission Type 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift PowrReverser No. of Speeds 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 12F/12R (standard); 24F/12R (optional) Max Travel Speed (Forward) 2WD: 18 mph; 4WD: 25 mph 12F/12R: 21.7 mph; 24F/12R: 24.9 mph (electronically limited) Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch with easy shift knob and electrohydraulic power shuttle lever Wet traction clutch Differential Lock & Limited Slip Options Hydraulic, electronically controlled; rear axle engaged via electrohydraulic rocker switch; 4WD front axle: hydraulic differential lock Pedal-operated differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Hydrostatic power steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Hydraulic wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Cab: mechanical swiveling seat with armrests, air-suspension swivel seat optional; Platform: mechanical spring-suspension seat with armrests Not Published Front Axle Type Heavy-duty 2WD or 4WD front axle Mechanical front wheel drive (MFWD) Front Axle Rating Not Published 6,615 lb Drawbar Capacity Not Published Standard: 2,755 lb; 2,425 lb (350 and 15.7 in extended). Heavy-Duty: 3,195 lb; 2,645 lb (350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 60.3 in (minimum, with std. 420/85R30 rear tires) Not Published Wheelbase 88.5 in 92.5 in Ground Clearance Not Published ROPS: 17 in; Cab: 15.2 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 100.8 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model Not Published 101.2 in Overall Length Not Published 159.13 in ▶ WeightTractor Weight (Base) 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb OOS: 7,275 lb (shipping weight); Cab: 8,150 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 420/85R30 standard Not Published R1 Agricultural - Front 2WD: 9.5L-15; 4WD: 340/85R24 12.4-24 R1 Agricultural - Rear 420/85R30 18.4-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System 931X and 936X: universal skid steer type quick release 520M; 540M Loader Model FL.3522, FL.3615, 931X, 936X 520M and 540M (previously H240 and H260) Loader Lift Height FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) 520M MSL: 132.0 in Loader Lift Capacity (Full Height) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force Not Published 520M MSL: 4,793 lb (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
