▶ EngineEngine Manufacturer AGCO Power FPT Industrial Engine Model 33 AWIC F5G Engine Type 3-cylinder, intercooled turbocharged diesel In-line, water-cooled, 4 stroke, CRDI No. of Cylinders 3 4 Displacement 201 in³ 206.7 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 100 hp 100.6 hp PTO Power 87 hp 85.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Dual element (primary and secondary) Dry Fuel System High-pressure common rail direct fuel injection CRDI (Bosch CP4.11) Alternator 80 A 120 A, 14 V ▶ HydraulicsPump Type Two-stage pump Gear pump type, engine drive Implement Flow Not Published 15.7 gpm Steering Flow Not Published 6.5 gpm Total Hydraulic Flow Not Published 22.2 gpm Overall Hydraulic Pump Flow Not Published 22.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 17.2 gpm Not Published No. of Standard Remote Valves 2 3 Pairs (Front), 2 Pairs (Rear) No. of Optional Remote Valves 1 1 Pair (Rear) ▶ Fluid CapacityFuel Tank Capacity 33 gal 30.4 gal Coolant Capacity 4.2 gal 3.2 gal Crankcase Capacity 3.3 gal 1.7-2.1 gal (6.5-2.1 gal) Transmission / Hydraulic System Capacity Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal 14.5 gal Front Axle Fluid Capacity Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive 1.4 gal ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Independent PTO Rear 540/540E standard; 540/1000 optional 540 / 750 / 1,000 Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 8,378 lb Hitch Lift Capacity (at 24”) 4,850 lb 5,952 lb Lift Control Type Not Published Position & Draft ▶ Transmission & DrivetrainTransmission Type 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift Power shuttle with Hi-Lo and Hand clutch No. of Speeds 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 24 X 24 Max Travel Speed (Forward) 25 mph 23.1 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Multidisc wet clutch with easy shift knob and electrohydraulic power shuttle lever Wet clutch disks Differential Lock & Limited Slip Options Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch; 4WD front axle Hydra-Lock Electro-Hydraulic Differential lock (EHD) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Hydrostatic Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Wet, Multi-disc Seat Suspension & Adjustability Cab: mechanical swiveling seat with armrests, air-ride swivel seat optional; Platform: mechanical spring suspension seat with armrests Air suspension seat Front Axle Type Heavy-duty 2WD or 4WD front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 152.2 in Overall Width 60.3 in (minimum, with std. 420/85R30 rear tires) 78.7 in Wheelbase 88.5 in 90 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 107 in ▶ WeightTractor Weight (Base) 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb 7,985 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 9,645 lb ▶ Tire OptionsTire Size & Options 2WD: 9.5L-15 front, 420/85R34 rear; 4WD: 340/85R24 front, 420/85R34 rear Ag 13.6-24 / 18.4-34; R14 340/70R28 / 460/75R38 R1 Agricultural - Front 2WD: 9.5L-15; 4WD: 340/85R24 13.6-24 R1 Agricultural - Rear 420/85R34 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System 931X and 936X: universal skid steer type quick release LL8100: ISO 24410 “Quick Attachment” (lever-lock with latch pins into the attachment latch groove) Loader Model FL.3522, FL.3615, 931X, 936X LL8100 Loader Lift Height FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) LL8100: 139.9 in Loader Lift Capacity (Full Height) FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) LL8100: 5,139 lb Loader Breakout Force Not Published LL8100: 5,313 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty
