▶ EngineEngine Manufacturer AGCO Power John Deere Engine Model 33 AWI HD PowerTech PWL 4045 Engine Type 3-cylinder turbocharged and intercooled diesel Diesel, turbocharged, aftercooled No. of Cylinders 3 4 Displacement 201 in³ 276 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 100 hp 100 hp PTO Power 75 hp 85 hp Engine Emissions Constraints Tier 4i Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner 2-stage dry Dry type with safety element Fuel System Common rail direct injection High Pressure Common Rail Alternator 120 A OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Single gear pump; tandem gear pumps optional Tandem gear pump (implement + steering) Implement Flow 15 gpm standard; 26 gpm with optional Twin Flow 15.9 gpm Steering Flow Not Published 6.6 gpm Total Hydraulic Flow 26 gpm (tandem pumps: 15 gpm to the 3-point hitch plus 11 gpm to remotes, combinable) 22.5 gpm Overall Hydraulic Pump Flow Not Published 22.5 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 15 gpm standard; 26 gpm with optional Twin Flow Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves Up to 4 3 ▶ Fluid CapacityFuel Tank Capacity 42 gal OOS: 25 gal; Cab: 30 gal Coolant Capacity 15.3 qt Cab: 3 gal; OOS: 2.5 gal Crankcase Capacity 13.7 qt 3.2 gal (with filter) Transmission / Hydraulic System Capacity 17.2 gal 11.5 gal Front Axle Fluid Capacity 5.3 qt axle beam; 0.85 qt each final drive MFWD differential housing: 1.3 gal; MFWD wheel hub (each): 0.74 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement and speed selection Independent, electrohydraulic engagement PTO Rear 540/540E standard; 540/540E/1000 optional 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 9,480 lb Not Published Hitch Lift Capacity (at 24”) 7,100 lb 4,630 lb Lift Control Type Electronically operated, lower-link draft sensing Top link draft sensing; mechanical hitch controls ▶ Transmission & DrivetrainTransmission Type Dyna-4 16x16 power shift and power shuttle (AUTO-DRIVE optional, 14:1 creeper optional) PowrReverser No. of Speeds 16F / 16R 12F/12R (standard); 24F/12R (optional) Max Travel Speed (Forward) 25 mph 12F/12R: 21.7 mph; 24F/12R: 24.9 mph (electronically limited) Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-disc, foot pedal and electronic control Wet traction clutch Differential Lock & Limited Slip Options Fully locking front and rear axle differentials, electro-hydraulically engaged Pedal-operated differential lock ▶ Chassis, Steering & ControlsFrame Type Rigid structural chassis; solid cast-steel flanged rear axle, internal planetary reduction Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Internal wet disc, hydraulic power assist, individual left and right foot pedals Hydraulic wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Mechanical suspended swivel seat, standard; manual or automatic air-suspension, optional Not Published Front Axle Type Adjustable 2WD, or fixed cast-steel 4WD (single-piece), outboard planetary final drives Mechanical front wheel drive (MFWD) Front Axle Rating 2WD: 6,085 lb; 4WD: 10,500 lb 6,615 lb Drawbar Capacity Not Published Standard: 2,755 lb; 2,425 lb (350 and 15.7 in extended). Heavy-Duty: 3,195 lb; 2,645 lb (350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 79.3 in Not Published Wheelbase 97.1 in 92.5 in Ground Clearance 17.6 in ROPS: 17 in; Cab: 15.2 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 100.8 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model 111.3 in (16.9R38 rear tires) 101.2 in Overall Length 167.5 in 159.13 in ▶ WeightTractor Weight (Base) 2WD: 8,426 lb; 4WD: 8,978 lb OOS: 7,275 lb (shipping weight); Cab: 8,150 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 radial agricultural tires only; 16.9R38 rear is the speed chart basis (16.9R34, 16.9R30, 18.4R30, 18.4R34, 13.6R38 listed) Not Published R1 Agricultural - Front Not Published 12.4-24 R1 Agricultural - Rear 16.9R38 18.4-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System MF931, MF941, MF946: quick attachment, single lever locking system 520M; 540M Loader Model MF931, MF941, MF946 520M and 540M (previously H240 and H260) Loader Lift Height MF931: 138 in; MF941: 148 in; MF946: 148 in (at pivot pins) 520M MSL: 132.0 in Loader Lift Capacity (Full Height) MF931: 3,880 lb; MF941: 4,735 lb; MF946: 3,965 lb (at pivot) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force Not Published 520M MSL: 4,793 lb (measured at pivot) ▶ WarrantyWarranty Length & Coverage 2-year/2,000-hour full coverage, all parts and labor Not Published
