▶ EngineEngine Manufacturer AGCO Power FPT Industrial Engine Model 33 AWI HD F5G Engine Type 3-cylinder turbocharged and intercooled diesel In-line, water-cooled, 4 stroke, CRDI No. of Cylinders 3 4 Displacement 201 in³ 206.7 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 100 hp 100.6 hp PTO Power 75 hp 85.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled (water-cooled) Water-cooled Air Cleaner 2-stage dry Dry Fuel System Common rail direct injection CRDI (Bosch CP4.11) Alternator 95 A 120 A, 14 V ▶ HydraulicsPump Type Single gear-type pump (tandem gear-type pumps with optional Twin Flow) Gear pump type, engine drive Implement Flow 15 gpm standard; 26 gpm with optional Twin Flow 15.7 gpm Steering Flow Not Published 6.5 gpm Total Hydraulic Flow 26 gpm (Twin Flow: 15 gpm to 3-point hitch plus 11 gpm to remotes, combinable) 22.2 gpm Overall Hydraulic Pump Flow Not Published 22.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 15 gpm standard; 26 gpm with optional Twin Flow Not Published No. of Standard Remote Valves 2 3 Pairs (Front), 2 Pairs (Rear) No. of Optional Remote Valves Up to 4 1 Pair (Rear) ▶ Fluid CapacityFuel Tank Capacity 42 gal 30.4 gal Coolant Capacity 15.3 qt 3.2 gal Crankcase Capacity 13.7 qt 1.7-2.1 gal (6.5-2.1 gal) Transmission / Hydraulic System Capacity 17.2 gal 14.5 gal Front Axle Fluid Capacity 5.3 qt axle beam; 0.85 qt each final drive 1.4 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement and speed selection Independent PTO Rear 540/540E standard; 540/540E/1000 optional 540 / 750 / 1,000 Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 9,480 lb 8,378 lb Hitch Lift Capacity (at 24”) 7,100 lb 5,952 lb Lift Control Type Electronic linkage control (ELC), position and draft control, lower link draft sensing Position & Draft ▶ Transmission & DrivetrainTransmission Type Dyna-4 16x16 power shift and power shuttle (AUTO-DRIVE optional, 14:1 creeper optional) Power shuttle with Hi-Lo and Hand clutch No. of Speeds 16F / 16R 24 X 24 Max Travel Speed (Forward) 25 mph 23.1 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-disc, foot pedal and electronic control Wet clutch disks Differential Lock & Limited Slip Options Fully locking front and rear differentials, electro-hydraulically engaged Electro-Hydraulic Differential lock (EHD) ▶ Chassis, Steering & ControlsFrame Type Rigid structural chassis, solid cast steel flanged rear axle with internal planetary reduction Not Published Steering Hydrostatic power steering, adjustable steering wheel Hydrostatic Brakes Internal wet disc, hydraulic power assist, individual left and right foot pedals Wet, Multi-disc Seat Suspension & Adjustability Mechanical suspended swivel seat standard; manual or automatic air suspension optional Air suspension seat Front Axle Type Adjustable 2WD or fixed cast steel 4WD, single piece with outboard planetary final drives Not Published Front Axle Rating 2WD: 6,085 lb; 4WD: 10,500 lb Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 167.5 in 152.2 in Overall Width 79.3 in 78.7 in Wheelbase 97.1 in 90 in Ground Clearance 17.6 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 108.5 in 107 in ▶ WeightTractor Weight (Base) 2WD: 8,426 lb; 4WD: 8,978 lb 7,985 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 9,645 lb ▶ Tire OptionsTire Size & Options R1 radial agricultural tires only; 16.9R38 rear is the speed chart basis (16.9R34, 16.9R30, 18.4R30, 18.4R34, 13.6R38 listed) Ag 13.6-24 / 18.4-34; R14 340/70R28 / 460/75R38 R1 Agricultural - Front Not Published 13.6-24 R1 Agricultural - Rear 16.9R38 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System MF931, MF941, MF946: Euro quick attach, single lever locking LL8100: ISO 24410 “Quick Attachment” (lever-lock with latch pins into the attachment latch groove) Loader Model MF931, MF941, MF946 LL8100 Loader Lift Height MF931: 138 in; MF941: 148 in; MF946: 148 in LL8100: 139.9 in Loader Lift Capacity (Full Height) MF931: 3,880 lb; MF941: 4,735 lb; MF946: 3,965 lb LL8100: 5,139 lb Loader Breakout Force Not Published LL8100: 5,313 lb ▶ WarrantyWarranty Length & Coverage 2-year/2,000-hour full coverage, all parts and labor 5-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty
