▶ EngineEngine Manufacturer AGCO Power FPT Engine Model 33 AWI HD F36 Engine Type 3-cylinder turbocharged and intercooled diesel 4-cylinder No. of Cylinders 3 4 Displacement 201 in³ Not Published Rated Engine Speed 2200 rpm Not Published Engine Power (Gross) 100 hp 101 hp PTO Power 75 hp 85 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled (water-cooled) Not Published Air Cleaner 2-stage dry Not Published Fuel System Common rail direct injection Not Published Alternator 95 A Not Published ▶ HydraulicsPump Type Single gear-type pump (tandem gear-type pumps with optional Twin Flow) Not Published Implement Flow 15 gpm standard; 26 gpm with optional Twin Flow Not Published Steering Flow Not Published Not Published Total Hydraulic Flow 26 gpm (Twin Flow: 15 gpm to 3-point hitch plus 11 gpm to remotes, combinable) 21 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow 15 gpm standard; 26 gpm with optional Twin Flow Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves Up to 4 Not Published ▶ Fluid CapacityFuel Tank Capacity 42 gal 34.3 gal Coolant Capacity 15.3 qt Not Published Crankcase Capacity 13.7 qt Not Published Transmission / Hydraulic System Capacity 17.2 gal Not Published Front Axle Fluid Capacity 5.3 qt axle beam; 0.85 qt each final drive Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement and speed selection Not Published PTO Rear 540/540E standard; 540/540E/1000 optional Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Not Published Hitch Lift Capacity 9,480 lb Not Published Hitch Lift Capacity (at 24”) 7,100 lb Not Published Lift Control Type Electronic linkage control (ELC), position and draft control, lower link draft sensing Not Published ▶ Transmission & DrivetrainTransmission Type Dyna-4 16x16 power shift and power shuttle (AUTO-DRIVE optional, 14:1 creeper optional) 12x12 electronic power shuttle No. of Speeds 16F / 16R 12 forward / 12 reverse Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet multi-disc, foot pedal and electronic control Not Published Differential Lock & Limited Slip Options Fully locking front and rear differentials, electro-hydraulically engaged Not Published ▶ Chassis, Steering & ControlsFrame Type Rigid structural chassis, solid cast steel flanged rear axle with internal planetary reduction Not Published Steering Hydrostatic power steering, adjustable steering wheel Not Published Brakes Internal wet disc, hydraulic power assist, individual left and right foot pedals Not Published Seat Suspension & Adjustability Mechanical suspended swivel seat standard; manual or automatic air suspension optional Air ride seat (standard); instructor seat available Front Axle Type Adjustable 2WD or fixed cast steel 4WD, single piece with outboard planetary final drives Class 1.0 HD heavy-duty front axle Front Axle Rating 2WD: 6,085 lb; 4WD: 10,500 lb Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 167.5 in Not Published Overall Width 79.3 in Not Published Wheelbase 97.1 in Not Published Ground Clearance 17.6 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 108.5 in Not Published ▶ WeightTractor Weight (Base) 2WD: 8,426 lb; 4WD: 8,978 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 radial agricultural tires only; 16.9R38 rear is the speed chart basis (16.9R34, 16.9R30, 18.4R30, 18.4R34, 13.6R38 listed) Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear 16.9R38 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System MF931, MF941, MF946: Euro quick attach, single lever locking Not Published Loader Model MF931, MF941, MF946 630LU; 635LU Loader Lift Height MF931: 138 in; MF941: 148 in; MF946: 148 in 143.9 in (630LU and 635LU) Loader Lift Capacity (Full Height) MF931: 3,880 lb; MF941: 4,735 lb; MF946: 3,965 lb 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, 31.5 in forward of the bucket pivot point) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage 2-year/2,000-hour full coverage, all parts and labor Not Published
