▶ EngineEngine Manufacturer AGCO Power John Deere Engine Model 44 AWFC PowerTech PWL 4045 Engine Type 4-cylinder, intercooled turbocharged, liquid-cooled diesel Diesel, turbocharged, aftercooled No. of Cylinders 4 4 Displacement 268.5 in³ 276 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 100 hp 100 hp PTO Power Power Shuttle: 83 hp; Dyna-4: 76 hp 85 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System High-pressure common-rail direct injection (HPCR) High Pressure Common Rail Alternator 80 A, 12 V OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Two high-pressure gear pumps Tandem gear pump (implement + steering) Implement Flow 15.1 gpm 15.9 gpm Steering Flow Not Published 6.6 gpm Total Hydraulic Flow 26 gpm 22.5 gpm Overall Hydraulic Pump Flow Not Published 22.5 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 26 gpm Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 1 3 ▶ Fluid CapacityFuel Tank Capacity 38.3 gal OOS: 25 gal; Cab: 30 gal Coolant Capacity Not Published Cab: 3 gal; OOS: 2.5 gal Crankcase Capacity Not Published 3.2 gal (with filter) Transmission / Hydraulic System Capacity Not Published 11.5 gal Front Axle Fluid Capacity Not Published MFWD differential housing: 1.3 gal; MFWD wheel hub (each): 0.74 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement via switch Independent, electrohydraulic engagement PTO Rear 540 / 540E / 1000 rpm 540/540E rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 7,710 lb 4,630 lb Lift Control Type Cab: electric controlled 3-point linkage with draft control; Platform: lever controlled 3-point linkage with draft control Top link draft sensing; mechanical hitch controls ▶ Transmission & DrivetrainTransmission Type Power Shuttle: 12F x 12R, 2 ranges, electro-hydraulic shuttle; Dyna-4: 16F x 16R powershift PowrReverser No. of Speeds Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse 12F/12R (standard); 24F/12R (optional) Max Travel Speed (Forward) 25 mph 12F/12R: 21.7 mph; 24F/12R: 24.9 mph (electronically limited) Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch with easy shift knob and electrohydraulic power shuttle lever Wet traction clutch Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock (rocker switch); hydraulic front differential lock on 4WD Pedal-operated differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Hydrostatic power steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Hydraulic wet disc brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Cab: air-suspension swivel seat; platform: mechanical spring-suspension seat with armrests Not Published Front Axle Type Heavy-duty 4WD front axle, center driveline Mechanical front wheel drive (MFWD) Front Axle Rating Not Published 6,615 lb Drawbar Capacity Not Published Standard: 2,755 lb; 2,425 lb (350 and 15.7 in extended). Heavy-Duty: 3,195 lb; 2,645 lb (350 and 15.7 in extended) ▶ Dimensions & ManeuverabilityOverall Width 64.8 in Not Published Wheelbase 95.7 in 92.5 in Ground Clearance Not Published ROPS: 17 in; Cab: 15.2 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 100.8 in Height to Top of ROPS (folded) Not Published 78.6 in Height to Top of Cab Model Not Published 101.2 in Overall Length Not Published 159.13 in ▶ WeightTractor Weight (Base) 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb OOS: 7,275 lb (shipping weight); Cab: 8,150 lb (shipping weight) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 460/85R34 standard radial Not Published R1 Agricultural - Front Not Published 12.4-24 R1 Agricultural - Rear Not Published 18.4-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published 520M; 540M Loader Model 941X; 946X; FL.3723; FL.3819 520M and 540M (previously H240 and H260) Loader Lift Height 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in 520M MSL: 132.0 in Loader Lift Capacity (Full Height) 941X: 2,220 lb; FL.3723: 2,840 lb (to full height, at 31.5 in forward of pivot pin) 520M MSL: 2,606 lb (to maximum height, measured at pivot) Loader Breakout Force FL.3723: 5,819 lb; FL.3819: 4,893 lb 520M MSL: 4,793 lb (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
