▶ EngineEngine Manufacturer AGCO Power Kubota Engine Model Not Published V3800CR-TIEF4 Engine Type 4-cylinder, intercooled turbocharged, liquid-cooled diesel 4-cylinder in-line, common rail direct injection, turbocharged with intercooler, DPF, DOC and SCR diesel No. of Cylinders 4 4 Displacement 268.5 in³ 230 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 100 hp 105.6 hp PTO Power Power Shuttle: 83 hp; Dyna-4: 76 hp 89 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System High-pressure common-rail direct injection (HPCR) Common rail direct injection Alternator 120 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Two high-pressure gear pumps Gear pump Implement Flow 15.1 gpm 15.9 gpm Steering Flow Not Published 5.4 gpm Total Hydraulic Flow 25.9 gpm 21.3 gpm Overall Hydraulic Pump Flow Not Published 21.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 26 gpm 15.9 gpm No. of Standard Remote Valves 2 1 standard (3 maximum) No. of Optional Remote Valves 1 2 optional (3 maximum) ▶ Fluid CapacityFuel Tank Capacity 38.3 gal 27.7 gal Coolant Capacity Not Published 11 qt Crankcase Capacity Not Published 11.3 qt Transmission / Hydraulic System Capacity Not Published 15.9 gal Front Axle Fluid Capacity Not Published 6.3 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement via switch Live-independent PTO, electro-hydraulic clutch with brake PTO Rear 540 / 540E / 1000 rpm 540 rpm (540/540E on 12-speed models) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 7055 lb (8860 lb optional) Hitch Lift Capacity (at 24”) 7,710 lb 5181 lb (8-speed); 7275 lb (12- and 24-speed) Lift Control Type Electronic linkage control (ELC) Position, draft (top link sensing) and mixed control ▶ Transmission & DrivetrainTransmission Type Power Shuttle: 12F x 12R, 2-range with electrohydraulic shuttle lever; Dyna-4: 16F x 16R powershift Fully synchronized main gear shift with electro-hydraulic shuttle (Hi-Lo dual speed on HDC24) No. of Speeds Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse 8 forward, 8 reverse (8-speed models); 12 forward, 12 reverse (12-speed models); 24 forward, 24 reverse (HDC24) Max Travel Speed (Forward) 25 mph 18.6 mph (8-speed); 23.6 mph (12-speed); 23.4 mph (24-speed) Max Travel Speed (Reverse) Not Published 18.4 mph (8-speed); 23.5 mph (12-speed) Clutch Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD Limited slip differential (front); mechanical differential lock (rear) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering; cab: tilt and telescopic column, platform: tilt column Hydrostatic power steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Hydraulic wet disc Seat Suspension & Adjustability Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest Front Axle Type Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5730 lb Drawbar Capacity Not Published 3300 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 155.9 in Overall Width 64.8 in 79.1 in Wheelbase 95.7 in 88.6 in Ground Clearance Not Published 19.7 in Min. Turn Radius without Brakes Not Published 13.8 ft Height to Top of ROPS Not Published 99.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 101.2 in ▶ WeightTractor Weight (Base) 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb 6173 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 460/85R34 standard radial Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 R1 Agricultural - Front Not Published 12.4-24 R1 Agricultural - Rear Not Published 18.4-30 R3 Turf - Front Not Published 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) R3 Turf - Rear Not Published 18.4-26 R3 or 19.5L-24 R3 R4 Industrial - Front Not Published 9.5L-15 F2 (rib front paired with the R4 rear) R4 Industrial - Rear Not Published 19.5L-24 R4 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick coupler standard (Euro type optional); quick-mount loader attach and detach without tools; single-lever hydraulic hose quick coupler optional Loader Model 941X; 946X; FL.3723; FL.3819 LA1854 Loader Lift Height 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in 145.7 in (height position); 131.9 in (power position) Loader Lift Capacity (Full Height) 941X: 3,650 lb; FL.3723: 4,519.5 lb 3990 lb (height position); 4144 lb (power position) Loader Breakout Force FL.3723: 5,818.6 lb; FL.3819: 4,892.9 lb Not Published ▶ WarrantyWarranty Length & Coverage Not Published 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours.
