▶ EngineEngine Manufacturer AGCO Power Doosan Engine Model Not Published Not Published Engine Type 4-cylinder, intercooled turbocharged, liquid-cooled diesel Turbocharged, four stroke intercooled, direct injection diesel No. of Cylinders 4 4 Displacement 268.5 in³ 208 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 100 hp 105 hp PTO Power Power Shuttle: 83 hp; Dyna-4: 76 hp 95.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System High-pressure common-rail direct injection (HPCR) Direct injection Alternator 120 A, 12 V 85 A ▶ HydraulicsPump Type Two high-pressure gear pumps Not Published Implement Flow 15.1 gpm 15.6 gpm Steering Flow Not Published 7.1 gpm Total Hydraulic Flow 25.9 gpm Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center, full-live electro-hydraulic with position and draft controls Rear Remote Hydraulic Flow 26 gpm Not Published No. of Standard Remote Valves 2 3 (mFORCE 105P); 2 (mFORCE 105S) No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 38.3 gal 33.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement via switch Electro-hydraulic PTO Rear 540 / 540E / 1000 rpm 540 @ 2220 rpm, 750 @ 2208 rpm, 1000 @ 2227 rpm (mFORCE 105P); 540 @ 2220 rpm, 1000 @ 2227 rpm (mFORCE 105S) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category 2 ball joints with telescopic lower links and adjustable outside stabilizers Hitch Lift Capacity Not Published 6,860 lb (measuring point not stated by Mahindra) Hitch Lift Capacity (at 24”) 7,710 lb Not Published Lift Control Type Electronic linkage control (ELC) Position and draft control ▶ Transmission & DrivetrainTransmission Type Power Shuttle: 12F x 12R, 2-range with electrohydraulic shuttle lever; Dyna-4: 16F x 16R powershift Power shuttle, power shift with synchromesh (mFORCE 105P); power shuttle with synchromesh (mFORCE 105S) No. of Speeds Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse 24F / 24R + 8 creepers (mFORCE 105P); 12F / 12R (mFORCE 105S) Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever Wet multi-plate Differential Lock & Limited Slip Options Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering; cab: tilt and telescopic column, platform: tilt column Hydrostatic power with tiltable column Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Wet disc Seat Suspension & Adjustability Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests Pneumatic suspension seat Front Axle Type Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 162 in Overall Width 64.8 in 84.3 in Wheelbase 95.7 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 11.98 ft Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 107 in ▶ WeightTractor Weight (Base) 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb 8,666 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 460/85R34 standard radial Not Published R1 Agricultural - Front Not Published 13.6R 24 R1 Agricultural - Rear Not Published 18.4R 34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 941X; 946X; FL.3723; FL.3819 105L Loader Lift Height 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in 105L: 141.7 in Loader Lift Capacity (Full Height) 941X: 3,650 lb; FL.3723: 4,519.5 lb 105L: 4,129 lb Loader Breakout Force FL.3723: 5,818.6 lb; FL.3819: 4,892.9 lb 105L: 6,025 lb ▶ WarrantyWarranty Length & Coverage Not Published 5-year limited powertrain warranty
