▶ EngineEngine Manufacturer AGCO Power Doosan Engine Model 44 AWFC DL03-LEA07 Engine Type 4-cylinder, intercooled turbocharged, liquid-cooled diesel 4-cylinder, in-line vertical, water-cooled No. of Cylinders 4 4 Displacement 268.5 in³ 208 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 110 hp 110 hp PTO Power Power Shuttle: 93 hp; Dyna-4: 86 hp 92.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Dual air cleaner Fuel System High-pressure common-rail direct injection (HPCR) Not Published Alternator 80 A, 12 V Not Published ▶ HydraulicsPump Type Two high-pressure gear pumps Gear Implement Flow 15.1 gpm Not Published Steering Flow Not Published Not Published Total Hydraulic Flow 26 gpm 31.5 gpm Overall Hydraulic Pump Flow Not Published 31.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 26 gpm Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 1 1 (third valve) ▶ Fluid CapacityFuel Tank Capacity 38.3 gal 34.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement via switch Independent PTO Rear 540 / 540E / 1000 rpm 540 / 1,000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 7,710 lb 8,003 lb Lift Control Type Cab: electric controlled 3-point linkage with draft control; Platform: lever controlled 3-point linkage with draft control Position, draft, mixed control ▶ Transmission & DrivetrainTransmission Type Power Shuttle: 12F x 12R, 2 ranges, electro-hydraulic shuttle; Dyna-4: 16F x 16R powershift Synchronized shuttle, power shuttle type No. of Speeds Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse 32F/32R Max Travel Speed (Forward) 25 mph 24.87 mph Max Travel Speed (Reverse) Not Published 24.69 mph Clutch Wet clutch with easy shift knob and electrohydraulic power shuttle lever Wet multi disc Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock (rocker switch); hydraulic front differential lock on 4WD Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Power steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Wet disc Seat Suspension & Adjustability Cab: air-suspension swivel seat; platform: mechanical spring-suspension seat with armrests Fully adjustable suspension swivel seat (deluxe cab) Front Axle Type Heavy-duty 4WD front axle, center driveline 4WD, electric/hydraulic engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.8 in 88.6 in Wheelbase 95.7 in 93.3 in Ground Clearance Not Published 19.5 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 109 in Overall Length Not Published 168.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb 9,064 lb (with cab and ag tires; cab is standard) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 460/85R34 standard radial R1 Agricultural: 13.6-24 front, 18.4-34 rear R1 Agricultural - Front Not Published 13.6-24 R1 Agricultural - Rear Not Published 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick attach (QA) bucket, 90 in; dual lever quick attach, built-in parking stand Loader Model 941X; 946X; FL.3723; FL.3819 KL1153 Loader Lift Height 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in KL1153: 143.3 in (at pivot pin) Loader Lift Capacity (Full Height) 941X: 2,220 lb; FL.3723: 2,840 lb (to full height, at 31.5 in forward of pivot pin) KL1153: 4,190 lb (at pivot pin) Loader Breakout Force FL.3723: 5,819 lb; FL.3819: 4,893 lb KL1153: 8,310 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
