▶ EngineEngine Manufacturer AGCO Power Deutz Engine Model 44 AWFC TCD 3.6L4-C5VT83E Engine Type 4-cylinder, intercooled turbocharged, liquid-cooled diesel Water-cooled, 4-cylinder diesel engine No. of Cylinders 4 4 Displacement 268.5 in³ 221 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 110 hp 111 hp PTO Power Power Shuttle: 93 hp; Dyna-4: 86 hp 107.3 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Dual dry Fuel System High-pressure common-rail direct injection (HPCR) CRDI Alternator 80 A, 12 V 120 A, 12 V ▶ HydraulicsPump Type Two high-pressure gear pumps Dual gear pump Implement Flow 15.1 gpm 14.3 gpm Steering Flow Not Published 7.1 gpm Total Hydraulic Flow 26 gpm 21.4 gpm Overall Hydraulic Pump Flow Not Published 21.4 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow 26 gpm Not Published No. of Standard Remote Valves 2 6 No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 38.3 gal 31.7 gal Coolant Capacity Not Published 19.1 qt Crankcase Capacity Not Published 8.5 qt Transmission / Hydraulic System Capacity Not Published 23.8 gal Front Axle Fluid Capacity Not Published 18.4 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement via switch Independent PTO Rear 540 / 540E / 1000 rpm 540/540E/1000 rpm (Reversible shaft) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 7,295 lb Hitch Lift Capacity (at 24”) 7,710 lb 6,007 lb Lift Control Type Cab: electric controlled 3-point linkage with draft control; Platform: lever controlled 3-point linkage with draft control Position/Draft ▶ Transmission & DrivetrainTransmission Type Power Shuttle: 12F x 12R, 2 ranges, electro-hydraulic shuttle; Dyna-4: 16F x 16R powershift Power shuttle & Hi-Lo shift No. of Speeds Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse F32 x R32 w/Creep Max Travel Speed (Forward) 25 mph 23 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch with easy shift knob and electrohydraulic power shuttle lever Wet multi-plate Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock (rocker switch); hydraulic front differential lock on 4WD Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Cab: tilt and telescopic steering column; Platform: tilt steering column Hydrostatic Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Wet, Multi disc Seat Suspension & Adjustability Cab: air-suspension swivel seat; platform: mechanical spring-suspension seat with armrests Air-ride full suspension seat Front Axle Type Heavy-duty 4WD front axle, center driveline 4WD, inboard planetary gear design Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 64.8 in 89.4 in Wheelbase 95.7 in 93.7 in Ground Clearance Not Published 16.7 in Min. Turn Radius without Brakes Not Published 159.5 in (left); 161 in (right) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 112.2 in Overall Length Not Published 175.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb 8,940 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 460/85R34 standard radial Not Published R1 Agricultural - Front Not Published 13.6-24 R1 Agricultural - Rear Not Published 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 941X; 946X; FL.3723; FL.3819 TL115SL Loader Lift Height 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in TL115SL: 144.4 in Loader Lift Capacity (Full Height) 941X: 2,220 lb; FL.3723: 2,840 lb (to full height, at 31.5 in forward of pivot pin) TL115SL: 4,129 lb Loader Breakout Force FL.3723: 5,819 lb; FL.3819: 4,893 lb TL115SL: 6,025 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours, parts and labor; loaders, backhoes and mid-mount mowers 12 months
