▶ EngineEngine Manufacturer AGCO Power KIOTI (Daedong) Engine Model Not Published 4J243TA-TP5B Engine Type 4-cylinder, intercooled turbocharged, liquid-cooled diesel In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4J243TA-TP5B) No. of Cylinders 4 4 Displacement 268.5 in³ 233.9 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 120 hp 115.3 hp PTO Power 99 hp 83.9 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid cooled Water-cooled Air Cleaner Not Published Dry element with evacuator valve Fuel System High-pressure common-rail direct injection (HPCR) Common Rail Direct Injection (CRDI) Alternator 120 A, 12 V Not Published ▶ HydraulicsPump Type Two high-pressure gear pumps Gear Implement Flow 15.1 gpm 19.8 gpm Steering Flow Not Published 12.2 gpm Total Hydraulic Flow 25.9 gpm 32 gpm Overall Hydraulic Pump Flow Not Published 32 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow 26 gpm Not Published No. of Standard Remote Valves 2 3 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 38.3 gal 47.6 gal Coolant Capacity Not Published 4.7 gal Crankcase Capacity Not Published 3.9 gal Transmission / Hydraulic System Capacity Not Published 20.34 gal Front Axle Fluid Capacity Not Published 2.6 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement via switch Independent PTO Rear 540 / 540E / 1000 rpm 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 8,079 lb Hitch Lift Capacity (at 24”) 9,390 lb 8,002 lb Lift Control Type Electronic linkage control (ELC) Electronic control ▶ Transmission & DrivetrainTransmission Type 12F x 12R, 2-range power shuttle with electrohydraulic shuttle lever Power Shuttle w/ Hi-Lo Shift No. of Speeds 12 forward, 12 reverse 24 forward / 24 reverse Max Travel Speed (Forward) 25 mph 23.83 mph Max Travel Speed (Reverse) Not Published 23.67 mph Clutch Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever Wet Multi Disc Differential Lock & Limited Slip Options Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD Mechanical rear differential lock (standard); front limited-slip differential ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering; cab: tilt and telescopic column, platform: tilt column Hydrostatic Power Steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Wet Multi Disc Seat Suspension & Adjustability Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Front Axle Type Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives 4WD with outboard planetary final drives and limited-slip differential Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 170.8 in Overall Width 64.8 in 88.6 in Wheelbase 98.4 in 94.9 in Ground Clearance Not Published 18.9 in Min. Turn Radius without Brakes Not Published 12.7 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 111.9 in ▶ WeightTractor Weight (Base) 4WD ROPS: 9,371 lb; 4WD Cab: 10,187 lb 10,230 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 460/85R34 standard radial R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) R1 Agricultural - Front Not Published 13.6-24 R1 Agricultural - Rear Not Published 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Loader Model 941X; 946X; FL.3723; FL.3819 KL1155 Loader Lift Height 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in KL1155: 150.6 in (to pivot pin) Loader Lift Capacity (Full Height) 941X: 3,650 lb; FL.3723: 4,519.5 lb KL1155: 4,216 lb (at pivot pins) Loader Breakout Force FL.3723: 5,818.6 lb; FL.3819: 4,892.9 lb KL1155: 8,554 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage Not Published Tractors (Non-Commercial): 24 months parts & labor, unlimited hours, 0% deductible; powertrain (engine and driveline): 48 months unlimited hours on HX Series
