▶ EngineEngine Manufacturer AGCO Power Mahindra Engine Model Not Published Not Published Engine Type 4-cylinder, intercooled turbocharged, liquid-cooled diesel 4-cylinder, liquid-cooled inline diesel No. of Cylinders 4 4 Displacement 268.5 in³ 215.6 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 120 hp 125 hp PTO Power 99 hp 106 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System High-pressure common-rail direct injection (HPCR) Common rail direct injection Alternator 120 A, 12 V Not Published ▶ HydraulicsPump Type Two high-pressure gear pumps Not Published Implement Flow 15.1 gpm 21.2 gpm Steering Flow Not Published 9.25 gpm Total Hydraulic Flow 25.9 gpm Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center with position & draft control, telescoping stabilizers & flex links Rear Remote Hydraulic Flow 26 gpm Not Published No. of Standard Remote Valves 2 2 (9125 S); 3 (9125 P) No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 38.3 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement via switch Independent PTO Rear 540 / 540E / 1000 rpm 540 @ 2220 rpm, 1000 @ 2227 rpm (9125 S); 540 @ 2220 rpm, 750 @ 2208 rpm, 1000 @ 2227 rpm (9125 P) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II with telescopic link ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 9,390 lb 5,787 lb (9125 S); 7,628 lb (9125 P) Lift Control Type Electronic linkage control (ELC) Electronic draft control with fender switches ▶ Transmission & DrivetrainTransmission Type 12F x 12R, 2-range power shuttle with electrohydraulic shuttle lever Power shuttle with synchromesh No. of Speeds 12 forward, 12 reverse 12F / 12R (9125 S); 24F / 24R + 8 creepers (9125 P) Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever Not Published Differential Lock & Limited Slip Options Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering; cab: tilt and telescopic column, platform: tilt column Power steering Brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Wet disc Seat Suspension & Adjustability Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests mComfort seat with adjustable air ride suspension, foldable adjustable armrest, recline and adjustable headrest Front Axle Type Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 169.3 in Overall Width 64.8 in 90.9 in Wheelbase 98.4 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 107 in ▶ WeightTractor Weight (Base) 4WD ROPS: 9,371 lb; 4WD Cab: 10,187 lb 9,385 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 460/85R34 standard radial Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid steer style quick attach couplers Loader Model 941X; 946X; FL.3723; FL.3819 9125L Loader Lift Height 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in 9125L: 162 in Loader Lift Capacity (Full Height) 941X: 3,650 lb; FL.3723: 4,519.5 lb 9125L: 5,415 lb Loader Breakout Force FL.3723: 5,818.6 lb; FL.3819: 4,892.9 lb 9125L: 6,874 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
